en-81
ADJUSTMENTS 7
7.10.7 BACKREST ADJUSTMENT (OPTION)
The backrest is adjusted using the locking lever (arrow).
• The locking lever must latch into the desired position. It should not be
possible to move the backrest into another position when it is locked.
7.10.8 FORE / AFT ISOLATOR (OPTION)
Under certain driving conditions (for example with a trailer attached), it is useful
to activate the fore/aft isolator. This means that shock impacts in the driving
direction can be better absorbed by the driver seat.
Position 1 = fore/aft isolator off
Position 2 = fore/aft isolator on
7.10.9 MULTIFUNCTION ARMREST (OPTION)
After releasing the hand wheel (arrow), the operator can adjust the armrest ver-
tical and longitudinal direction; the armrest inclination can be adjusted as well.
The vertical and longitudinal adjustment are effected at the same time in per-
ceptible steps.
• After adjustment has been terminated, tighten the hand-wheel safely
