8 MAINTENANCE AND LUBRICATION
8.1 MAINTENANCE AND LUBRICATION CHARTS ______________________________
MACHINE SERVICE INTERVAL CHART
Interval Item Section
First 50 hours
 Change the Hydraulic Filter Elements
8.7
Each day
10 hours
 Check Safety Interlock System
 Check the Hydraulic Fluid Level
 Check Tyre Pressure
 Check Engine Bay for Dirt
6.2
8.6
8.17
8.22
Each week
Every 50 hours
 Check for Loose Components
 Check Cutter Blades
 Check for Hydraulic Leaks
8.12
8.20
3.1.8
End of season
Every 1000
hours
 Check Battery Condition
 Change the Hydraulic Oil and Filters
8.12
8.6
Lubricate these fittings every week
A = All Lift Arm Pivots.
B = All Cutter Deck Caster Wheel Pivots.
FLUID REQUIREMENTS
Quantity Type
Engine Oil (with filter) 9.5 litres 2.1 Imp gals 2.51 US gals 10-30W (see specification below)
Hydraulic Oil (with filter) 50.2 litres 11.0 Imp gals 13.3 US gals Total Equivis ZS46 (ISO VG 46)
Radiator Coolant 7.6 litres 1.67 Imp gals 2.0 US gals 50% Anti-Freeze
Fuel 77.1 litres 17 Imp gals 20.3 US gals #2-D (ASTM D975) Diesel
Engine oil:Must be to A.P.I. Classification CJ-4 grade.
TEMPERATURE VISCOSITY
Above 25°C (77°F) SAE30 or SAE10W-30 or 15W-40
0°C to 25°C (32°F to 77°F) SAE10W-30 or 15W-40
Below 0°C (32°F) SAE10W-30
TYRE PRESSURE
Product
Front Wheel Rear Wheel
Tyre Size Tyre Type Tyre Pressure Tyre Size Tyre Type Tyre Pressure
HR600
HR700
26 x 12.00 - 12
Grassmaster
6pr
1.37 - 1.72 bar
(20-25 psi)
20.00 x 10.00 - 8
Grassmaster
4pr
1.37 - 1.72 bar
(20-25 psi)
26 x 12.00 - 12 Armour 6pr
1.37 - 1.72 bar
(20-25 psi)
20.00 x 10.00 - 8 Armour 6pr
1.37 - 1.72 bar
(20-25 psi)
