Jacuzzi J-200 User Manual

J-200
16.2 J-215 and J-225 Convertible Power Models (For a 3-wire
120V 60 Hz connection)
A. This wiring diagram is used for all 1-Pump 120V 3-Wire 60 Hz
convertible spa models.
SENSOR A
SENSOR B
1.0 kW HEATER
BLK
GFCI
WHT
GRN
1A SLO-BLOW
F4
1A SLO-BLOW
F5
TB1
1 2 3
K5 K1
K2
K4
K3
F6 30A 250VAC
T1
J16 J17
J23
SERIAL
J5
REMOTE
RELAY BOARD
J28 AUX FRZ
J35
J34
K7
K12
120V 120V
240V
J24
J9
PUMP 1
J19
J21
OZONE
J33
A/V
1
2
J4
J8
J18
J55
J3
J6
J51
J1
J27
J110
J13
HEATER 1
J2
J7
3
J20
J10
J12
J88
J22
ON
S1
J31 J30
J109
J15
LIGHT
J52
J46
J38
J11
HEATER 2
1 8
J56
J57
0.16A SLO-BLOW
F3
UV
USE EARTH GROUND CONNECTIONS AS INDICATED INSIDE SYSTEM ENCLOSURE
TOTAL OUTPUT AMP DRAW NOT TO EXCEED MAX INPUT RATING OF SPA
DANGER
Turn power off
before servicing. This
task should only be
performed by a quali-
fied technician.
!
RISK OF SHOCK OR
ELECTROCUTION!
HAND TIGHTEN WITH PHILIPS SCREWDRIVER.
WIRE STRIP LENGTH
11/16” (0.69”, 17.5mm)
BARE METAL
58
