22
WARNING!
Do not get in the spa until the quantity of disinfectant has not
dropped below the level recommended by the manufacturer
and/or by your retailer.
Always check water temperature carefully before entering spa.
Control Panel
Control panel for models with 2 pumps.
A Display: can display current water temperature, water tem-
perature set point, selected skimming/heating mode, and error
messages.
B. ( + ) Button: increases water temperature set point.
C. ( - ) Button: decreases water temperature set point.
The range of temperature adjustment goes from 18 to 40 °C.
Factory default setting is 38 °C.
D. Light button: turns the lighting on and off for the cascade and
for the bottom of the spa, the cup holder and the headrest. Press
in sequence to go from high to medium to low intensity. Press
a fourth time to turn the light off.
E. Light colour button. Selects one of the 5 available colours
for lighting for the cascade, the spa bottom, the cup holder and
the headrest.
F. Jets 1 Button: turns jets pump 1 on and off. Press once for
low speed; press a second time for high speed; press a third time
to turn pump off.
G. Jets 2 button (only for models with 2 pumps): turns the high
speed jets of pump 2 on and off. Press once to turn them on;
press twice to turn the pump off.
H. Heat Indicator: lit when heater is on.
HA
B
C
D
E
F
G
HA
B
C
D
E
F
G
10
4
37
1
2 2
Flow
8
5
6 6
9
11
1 Electrical box
2 Power supply entrance(s)
3 2-Speed Pump (pump 1)
4 Heater
5 Drain valve
6 Pump drain plug(s)
7 1-Speed pump (pump 2)
8 Circulation pump
9 Ozonator (optional)
10 Injector (optional, required for Ozonator)
11 Display
