Test and Configuration Settings 8-1
Revision 2 - 26 April, 2000 HP SERIES DIMMER TECHNICAL MANUAL
8.0 Technical Data and Specifications
PARAMETER HP12-TR HP12-SC HP12-WMTR HP12-WMSC HP6-C
No. of Channels: 12 6
Input Power
Requirements:
3 Phases plus Neutral and Earth
200-265 volts phase-to-neutral
345-460 Volts AC Phase-Phase +/-10%
46 Amps / Phase 50 Amps / Phase
Full size (min 46A) Neutral conductor
Max upstream protection 50A per phase
(min 50A)
Load Power per chan: 20VA - 2.5kVA 5VA - 2.5kVA 20VA - 2.5kVA 5VA - 2.5kVA 40VA - 6kVA
Max Dissipation: <24W/chan
(<300W total)
<35W/chan
(<500W total)
<24W/chan
(<300W total)
<35W/chan
(<500W total)
<65W/chan
(<400W total)
Max Ambient Temp: 45ºC
Control Signal: DMX-512 (1990) Protocol
DMX Connectors: AXR-5-21B,
AXR-5-22B
AXR-5-21B,
AXR-5-22B
Six-way screw
terminal block
Six-way screw
terminal block
AXR-5-21B,
AXR-5-22B
Test Function Level: 0 to Full with detent each step
LED Indicators: Status, Control and Output mimics; DMX; Phases A, B & C
Output Protection: 12 x 11.5 amp circuit breakers 6 x 25 amp circuit
breakers
Undervoltage Limit 100V+/-10%
Neutral - Earth
Voltage Limit
15V+/-10%
Cooling System 1 x 80mm speed
controlled fan
2 x 80mm speed
controlled fans
1 x 80mm speed
controlled fan,
aided by
convection
2 x 80mm speed
controlled fans,
aided by
convection
2 x 80mm speed
controlled fans
Gate Firing System Opto-Isolator Continuous DC
gate firing
Opto-Isolator Continuous DC
gate firing
Opto-Isolator
Control Devices 12 x 40A Triac 24 x 35A SCR 12 x 40A Triac 24 x 35A SCR 12 x 65A SCR
Output risetime @
50% dim
(10% - 90%, 2500W
incandescent load)
280 µsec +/-10% 500 µsec +/-10% 280 µsec +/-10% 500 µsec +/-10% 500 µsec +/-10%
Power Supply Entry: 2 metre tail with
Clipsal 56P532
plug
2 metre tail with
Clipsal 56P532
plug
Internal terminal
block
Internal terminal
block
2 metre tail with
Clipsal 56P550
plug
Output Connectors:
(Australia)
1 x 10 amp
Clipsal 415 per
channel
1 x 10 amp
Clipsal 415 per
channel
Internal terminal
blocks
Internal terminal
blocks
2 x 20 amp
HPM CAT38 per
channel (parallel)
