Technical Data and Specifications 8-3
Revision 2 - 26 April, 2000 HP SERIES DIMMER TECHNICAL MANUAL
8.1 Multipin output connector pin-outs
19 PIN SOCAPEX CONNECTORS
PIN No OUTPUTS 1-6 OUTPUTS 7-12
1 ACTIVE 1 ACTIVE 7
2 NEUTRAL 1 NEUTRAL 7
3 ACTIVE 2 ACTIVE 8
4 NEUTRAL 2 NEUTRAL 8
5 ACTIVE 3 ACTIVE 9
6 NEUTRAL 3 NEUTRAL 9
7 ACTIVE 4 ACTIVE 10
8 NEUTRAL 4 NEUTRAL 10
9 ACTIVE 5 ACTIVE 11
10 NEUTRAL 5 NEUTRAL 11
11 ACTIVE 6 ACTIVE 12
12 NEUTRAL 6 NEUTRAL 12
13 EARTH 1 EARTH 7
14 EARTH 2 EARTH 8
15 EARTH 3 EARTH 9
16 EARTH 4 EARTH 10
17 EARTH 5 EARTH 11
18 EARTH 6 EARTH 12
19 NOT CONNECTED NOT CONNECTED
