23
MC450e
Hoop Adjust key
Hoop Adjustment
Adjustment
1. Remove the presser foot.
2. Turn the power switch OFF.
Attach the embroidery hoop and the template.
3. Turn the power switch ON while pressing the Start/
Stop button to enter the factory setting mode.
4. Press “Hoop Adjust” key.
5. The hoop moves to its start position.
(Default position: X=1000 Y=1400)
6. Adjust the hoop position so that the needle drops to
the center of the template hole.
Press or key to adjust the hoop position right
or left (X value).
Press or key to adjust the hoop position
forward or backward (Y value).
7. Press OK to register the setting.
Needle
Match the needle drop
position and the center of
the template hole.
Template
X value
Y value
Left
Right
Forward
Backward
