Maintenance
Engine
99 9831/7750-1 99
WARNING Do not try to turn the engine by pulling the fan or fan belt. This could cause injury or premature
component failure.
CAUTION Make sure the engine cannot be started. Disconnect the battery before doing this job, otherwise
you could be injured.
Figure 54.
A Cracks B Fraying
C Missing pieces
1. Make the machine safe.
Refer to: Maintenance Positions (Page 87).
2. Inspect the belt for cracks, fraying or missing pieces.
3. If necessary, install the new drive belt.
Refer to: Replace (Page 99).
Replace
