INTRODUCTION
PRODUCT
REFERENCE AND ILLUSTRATIONS
PRODUCT REFERENCE
AND
ILLUSTRATIONS
Bombardier Motor Corporation of America
reserves the right to make changes at any time,
without notice,
in
specifications and models and
also to discontinue models. The right
is
also
reserved to change any specifications or parts, at
any time, without incurring any
obligation to equip
same on
models manufactured prior to date of
such change. Specifications used are based
on
the latest product information available at the time
of
publication.
The continuing accuracy of this manual cannot
be
guaranteed.
All photographs and illustrations used
in
this man-
ual may not depict actual models or equipment,
but are intended
as
representative views for refer-
ence
only.
Certain features or systems discussed
in
this
manual might not be found
on
all models
in
all
marketing areas.
All
service technicians must
be
familiar with nauti-
cal orientation. This manual often identifies parts
and procedures using these terms.
FORWARD
Nautical
Orientation
14
SYMBOLS
Throughout this service manual, symbols are
used to interpret
electrical troubleshooting results
or to assign values
in
drawings.
Electrical
When
"00"
shows
on
the meter face, no continuity,
or very high resistance,
is
indicated. The symbol
is
referred to
as
infinity.
When
"V" follows a value
on
the meter face, the
procedure
is
measuring voltage.
v
DR4204
