– 6 –
7. Installing the thread stand
1) Assemble the thread stand unit, and insert it in the
hole in the machine table.
2) Tighten nut
.
6. Adjusting the height of the knee lifter
1) The standard height of the presser foot lifted using the knee lifter is 10 mm.
2) You can adjust the presser foot lift up to 13 mm using knee lifter adjust screw
.
3) When you have adjusted the presser foot lift to over 10 mm, be sure that the bottom end of needle bar
in its lowest position does not hit presser foot
.
WARNING :
Be sure to turn the power OFF before the following work in order to prevent personal injury due to
unintentional starting of the sewing machine.
To Next Page
