JUKI DDL-8700-7 Engineer's Manual

(7) Adjustment of the position of the moving knife
Standard adjustment
Center of needle
Most retreated position Home position
0.5 mm
(0.2 to 0.7)
3.5
mm
0 _
0.5
1) Proper position of the moving knife
2) How to position the moving knife
3) When the moving knife can not be properly positioned merely by adjusting the position of the
link driving magnet pin
❶
❸
❷
❹
❺
❻
❾
❼
❽
❿
❽
V-slit used for
adjusting the
position of the
moving knife
− 16 −

JUKI DDL-8700-7 Specifications

General

Max Stitch Length	5 mm
Needle Bar Stroke	30.7 mm
Lift of the Presser Foot	By hand: 5.5 mm, By knee: 13 mm
Lubrication	Automatic
Needle	DB×1
Hook	Full rotary hook
Power Requirement	Single-phase 100~120V, 200~240V
Motor	Direct-drive servo motor
Weight	45 kg
