JUKI DDL-8700-7 Engineer's Manual

2) Machine head list
No. Machine head Contents of displayType
1 DDL-9000B MA/MS/SS
2 DDL-9000B DS
3 DDL-9000B SH
4 DDL-9000A MA/MS/SS
5 DDL-9000A DS
6 DDL-9000A SH
7 LH-3528/68A
∗
Machine head set at the time of delivery
∗
Number of revolutions at
the time of delivery (sti/min)
Max. number of
revolutions (sti/min)
4000 5000
4000 4000
4000 4500
4000 5000
4000 4000
4000 4500
3000 3000
(Caution) 1. When the dry-type machine head is connected, any model other than dry-type one
cannot be set.
2. Refer to the machine head list (40088647) for the details of each machine head.
dLbM
dLbd
dLbH
dLAM
dLAd
dLAH
H35d
8
9
10
11
12
13
14
15
16
17
DLN-9010
DDL-8700
DDL-5600J
DDL-5600L,U,R
DDL-5550
DLU-5490
DLD-5430
DLN-5410
DLM-5400
LZ-2280
Ln9S
dL87
dL6J
dL6L
dL50
LU90
Ld54
Ln54
LM54
Z280
4000 5000
4000 5000
4000 4000
3000 3000
4000 5000
4000 4500
4000 4500
4000 5000
4000 4500
4000 5000
− 43 −

JUKI DDL-8700-7 Specifications

General

Max Stitch Length	5 mm
Needle Bar Stroke	30.7 mm
Lift of the Presser Foot	By hand: 5.5 mm, By knee: 13 mm
Lubrication	Automatic
Needle	DB×1
Hook	Full rotary hook
Power Requirement	Single-phase 100~120V, 200~240V
Motor	Direct-drive servo motor
Weight	45 kg
