– 9 –
Procedures of assembling
1. Mounting of the main shaft motor together with the coupling
1) Tighten the four motor set screws
4
. Then, tighten the two set screws
5
on the main shaft side
of the coupling
2
.
2) The cords of the main shaft motor
3
should be positioned in the sidewise direction.
2. Incorporation of the coupling in the main shaft motor
1) Provide a clearance of 0.5 mm between the coupling
2
and the main shaft motor
3
.
2) Apply the No. 1 screw
5
of the coupling
2
to the shaft at section of the main shaft motor
3
,
and x it.
3. Meshing of the coupling
1) Apply the set screw
6
(No. 1 screw) of the main shaft motor side to the section between the two
set screws
5
of the main shaft, and get them meshed.
To Next Page
