– 78 –
Name of parts Type Part No. Remarks
Feed plate blank
t = 1.2
Without knurl / processed
Sewing area lengthwise 20 × crosswise 40
14120109
With knurl / processed
Sewing area lengthwise 20 × crosswise 40
14120307
Without knurl / stainless steel
Sewing area lengthwise 20 × crosswise 40
14120505 t = 0.5
Without knurl / processed
Sewing area lengthwise 30 × crosswise 40
40021855
Without knurl / without processing
Sewing area lengthwise 30 × crosswise 40
40021856
Without knurl / stainless steel
Sewing area lengthwise 30 × crosswise 40
40021857 t = 0.5
With knurl / processed
Sewing area lengthwise 30 × crosswise 40
40021858
With knurl / without processing
Sewing area lengthwise 30 × crosswise 40
40021859
Work clamp foot face plate (asm.) 14121263 Face plate
for presser
blank
Presser blank
t = 3.2
With knurl / Processed (right)
Sewing area lengthwise 20 × crosswise 40
14121701
With knurl / Processed (Left)
Sewing area lengthwise 20 × crosswise 40
14121800
With knurl / Processed (right)
Sewing area lengthwise 30 × crosswise 40
40021851
With knurl / Processed (Left)
Sewing area lengthwise 30 × crosswise 40
40021852
With knurl / without processing (right)
Sewing area lengthwise 30 × crosswise 40
40021853
With knurl / without processing (Left)
Sewing area lengthwise 30 × crosswise 40
40021854
Needle hole guide
φA
φB
A=1.6 B=2.6 With relief slit B2426280000 S type
A=1.6 B=2.0 Without relief slit D2426282C00 F and M
types
A=2.3 B=4.0 Without relief slit 14109607 H and W
types
A=2.7 B=3.7 Without relief slit D2426MMCK00 For extra
heavy-
weight mate-
rial
(2) Table of optional parts
