ā€“ 99 ā€“
6. Engraved marker dots on the handwheel (for the machine with thread
trimmer only)
UP stop position
(One marker dot)
Adjustment of thread
trimmer cam
(Two marker dots)
Adjustment of opener timing
(Three marker dots)
