JUKI LU-2828-7 - Presser Foot Lift Adjustment

– 16 –
(7) Lift of the presser foot
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of the
sewing machine.
Standard adjustment
1) Hand lifter
❻
❶
❼
[Conditions]
• State that the hand lifter is raised.
❹
❺
10 mm
❷
❸
❷
❸
