4. Selective parts and consumable parts
o
Selective parts
Part name Part No. Remarks Model
Hook shaft selective washer B255728000A t=1.15 to 1.2 mm
Hook shaft selective washer B255728000B t=1.05 to 1.1 mm
Hook shaft selective washer B255728000C t=0.9 to 0.95 mm
Hook shaft selective washer B255728000D t=0.8 to 0.85 mm
Hook shaft selective washer B255728000E t=0.975 to 1.025 mm
Rocking link pin A 40149115 Shaft diameter ø8.001 to ø8.006 mm LU-2828-6, 2828-7
LU-2818-7, 2868-7
Rocking link pin B 40149116 Shaft diameter ø7.997 to ø8.002 mm LU-2828-6, 2828-7
LU-2818-7, 2868-7
Rocking link pin C 40149117 Shaft diameter ø7.993 to ø7.998 mm LU-2828-6, 2828-7
LU-2818-7, 2868-7
Rocking link pin D 40149118 Shaft diameter ø7.989 to ø7.994 mm LU-2828-6, 2828-7
LU-2818-7, 2868-7
Feed adjusting pin A 40149120 Shaft diameter ø8.001 to ø8.006 mm LU-2828-6, 2828-7
LU-2818-7, 2868-7
Feed adjusting pin B 40149121 Shaft diameter ø7.997 to ø8.002 mm LU-2828-6, 2828-7
LU-2818-7, 2868-7
Feed adjusting pin C 40149122 Shaft diameter ø7.993 to ø7.998 mm LU-2828-6, 2828-7
LU-2818-7, 2868-7
Feed adjusting pin D 40149123 Shaft diameter ø7.989 to ø7.994 mm LU-2828-6, 2828-7
LU-2818-7, 2868-7
Feed rod pin A 40149125 Shaft diameter ø8.001 to ø8.006 mm LU-2828-6, 2828-7
LU-2818-7, 2868-7
Feed rod pin B 40149126 Shaft diameter ø7.997 to ø8.002 mm LU-2828-6, 2828-7
LU-2818-7, 2868-7
Feed rod pin C 40149127 Shaft diameter ø7.993 to ø7.998 mm LU-2828-6, 2828-7
LU-2818-7, 2868-7
Feed rod pin D 40149128 Shaft diameter ø7.989 to ø7.994 mm LU-2828-6, 2828-7
LU-2818-7, 2868-7
Moving knife spacer t=0.4 40147932 t=0.35 to 0.45 mm LU-2828-6, 2828-7
Moving knife spacer t=0.5 40147933 t=0.45 to 0.55 mm LU-2828-6, 2828-7
Moving knife spacer t=0.6 40147934 t=0.55 to 0.65 mm LU-2828-6, 2828-7
Moving knife spacer t=0.7 40147935 t=0.65 to 0.75 mm LU-2828-6, 2828-7
Moving knife spacer t=0.8 40147936 t=0.75 to 0.85 mm LU-2828-6, 2828-7
Counter knife spacer t=0.2 40155295 t=0.15 to 0.25 mm LU-2818-7, 2868-7
Counter knife spacer t=0.4 40155296 t=0.35 to 0.45 mm LU-2818-7, 2868-7
Counter knife spacer t=0.6 40155297 t=0.55 to 0.65 mm LU-2818-7, 2868-7
Counter knife spacer t=0.8 40155298 t=0.75 to 0.85 mm LU-2818-7, 2868-7
Counter knife spacer t=1.0 40155299 t=0.95 to 1.05 mm LU-2818-7, 2868-7
Counter knife spacer t=1.2 40157628 t=1.15 to 1.25 mm LU-2818-7, 2868-7
Counter knife spacer t=1.4 40157629 t=1.35 to 1.45 mm LU-2818-7, 2868-7
Clamp spring spacer t=0.2 40155301 t=0.15 to 0.25 mm LU-2818-7, 2868-7
Clamp spring spacer t=0.4 40155302 t=0.35 to 0.45 mm LU-2818-7, 2868-7
Clamp spring spacer t=0.6 40155303 t=0.55 to 0.65 mm LU-2818-7, 2868-7
Clamp spring spacer t=0.8 40155304 t=0.75 to 0.85 mm LU-2818-7, 2868-7
Clamp spring spacer t=1.0 40155305 t=0.95 to 1.05 mm LU-2818-7, 2868-7
Clamp spring spacer t=1.2 40157625 t=1.15 to 1.25 mm LU-2818-7, 2868-7
Clamp spring spacer t=1.4 40157626 t=1.35 to 1.45 mm LU-2818-7, 2868-7
