JUKI MCS-1500 User Manual

Threading
Threading preparation / TIPS
・
Switch the machine off (power switch "0").
・
Fully raise support rod with thread guide.
・
Open the looper cover and cloth plate.
・
Turn handwheel until the looper is at its leftmost position.
・
Raise the presser foot to release the tensions.
・
Thread the looper rst and then the needle(s).
Thread guide bar
Slide thread into the two slits to form an S-loop.
Thread tension
The thread must lie correctly between the tension discs
for perfect stitch formation. When a slight resistance is
felt on the thread, it is lying correctly between the tension
discs.
12

JUKI MCS-1500 Specifications

General

Presser Foot Lift	8 mm
Number of Threads	2/3
Stitch Length	1.0-4.0 mm
Differential Feed	0.7-2.0
Maximum Sewing Speed	1350 stitches per minute
Number of Needles	2
