JUKI MCS-1500 User Manual

Technical data
Stitch choice Cover stitch: 3 needles, 1 looper: 5 mm (0.2”)
2 needles, 1 looper: 5 mm (0.2”)
2 needles, 1 looper: 2.5 mm (0.1”)
Chainstitch: 1 needle, 1 looper
Needle system 130/705H
Stitch width Cover stitch: 5 mm (0.2”)
Stitch length 1-4 mm
Differential feed no waving in knits N-2
no puckering 0.7-N
Presser foot lift 8 mm / 10 mm
Presser feet Cover stitch (compensating foot), snap on sole
Chainstitch (Optional Accessories), with tape guide, snap on sole
Handwheel Rotates counterclockwise
Sewing speed up to 1350 sti/min
Weight 6.8 kg
Dimensions 280 (L) x 335 (W) x 285 (H) mm
Foot control model No. YC-482 (USA and Canada only)
YC-483N (220-240V)
We reserve the rights to make changes in the interest of technical progress.
34

JUKI MCS-1500 Specifications

General

Presser Foot Lift	8 mm
Number of Threads	2/3
Stitch Length	1.0-4.0 mm
Differential Feed	0.7-2.0
Maximum Sewing Speed	1350 stitches per minute
Number of Needles	2
