Threading 4 thread cover stitch
1
3
2
4
5
6
7
8
9
10
10
9
4
5
6
3. Threading center cover stitch needle
(green)
• Switch the machine off (Power switch to “0”).
Place the spool on the spool holder pin as illustrated.
(1) Bring the thread up and take it from back to front
through the guide.
(2, 3) Make an S-loop around thread guide bar.
(4) Thread the tension dial.
(5, 6) Thread the guides.
(7) Thread the take up.
(8) Thread the guide.
(9) Thread the needle clamp guide.
(10) Thread the center needle eye from front to back and
lay the thread over the presser foot to the left. Cut the
thread to about 7 cm (3”).
Note:
If the looper thread has to be re-threaded, cut the needle
threads above the needle eye and remove. Thread the
looper rst and then the needles.
15
