JUKI MO-6714S Engineer's Manual

Standard Adjustment
(11) Adjusting the height of the feed dog
The height of main feed dog O from the top surface of the throat plate O should be as follows when
it is
at its highest posion.
•
Needle A
8 entry
I
I
'
Model
MO-6.600S Series
MO-6904G Series
MO-6914G Series
MO-6916G Series
(Unit: mm)
Dimension A
-
1.0
1.3
1.2
1.1
Auxiliary feed dog 8 is 0.5 mm lower than main feed dog &.
-05mm
• •
(12) Adjusting the tillt of the feed dog
Tilt of the feed dogs when the feed dogs
have come up most.
•
Front up
(Unit: mm)
Model
Dimension A
DimensionB
MO-6.t!:.0OS Series
1.0
(1.2)
M0-6904G Series
1.3 (1.5)
MO-6914G Series
1.2
(1.4)
-
MO-6916G Series
1.1
(1.3)
When the feed dog iuts out the top surface of
the throat plate
Feed dog is
Top surface of leveled.
thethr\pla~
N\MI\
-24-
