−16 −
38
39
40
41
42
43
One-shot
speed
Pedal stroke at
the start of
rotation
Low speed
section of
pedal
Starting
position of
lifting presser
foot by pedal
Starting
position of
lowering
presser foot
Pedal stroke 2
for starting
thread trimming
One-shot speed (The max. value depends on the number of rotation of
the sewing machine head.)
Position where the sewing machine starts rotating from pedal neutral
position (Pedal stroke)
Position where the sewing machine starts accelerating from pedal neutral
position (Pedal stroke)
Position where the cloth presser starts lifting from pedal neutral position
(Pedal stroke)
Starting position of lowering presser foot
Stroke from the neutral position
Position 2 where the thread trimming starts from pedal neutral position
(When the function of lifting presser foot by pedal is provided.) (Pedal
stroke)
150 to MAX
(r.p.m.)
10 to 50
(0.1 mm)
10 to 100
(0.1 mm)
–60 to –10
(0.1mm)
8 to 50
(0.1 mm)
–60 to –10
(0.1 mm)
*
Item
Function of
changeover of
compensating
switch on the
operation panel
function
Function of fine
adjustment of
number of
rotation
Thread
trimming
motion
condition
Function of
setting the
holding force
after stop
Function of
setting the
reaction force
at the time of
retry
Suction time of
the first start of
the back
solenoid
Function of
reverse feed
stitching on the
way
Number of
stitches of
reverse feed
stitching on the
way
Effective
condition of
reverse feed
stitching on the
way when the
sewing
machine is
stopping.
Thread
trimming
function by
reverse feed
stitching on the
way
Number of
rotation at a
low speed
Number of
rotation of soft-
start
No.
22
24
25
26
27
29
30
31
32
33
35
37
Setting
range
0/1
–1.5% to
1.5%
(0.1 %)
0/1
0 to 9
0 to 15
50 to 300
(ms)
0/1
0 to 19
(Stitches)
0/1
0/1
150 to 250
(r.p.m.)
150 to MAX
(r.p.m.)
Description
Function of needle up/down compensating switch on the operation panel
can be changed.
0 : Needle up/down compensation
1 : One stitch compensation
Number of rotation can be compensated.
Be sure to normally use this function with "0".
This function sets the thread trimming motion after DOWN position has
been off by turning handwheel by hand.
0 : Thread trimming after turning handwheel by hand is permitted.
1 : Thread trimming after turning handwheel by hand is prohibited.
This function prevents the sewing machine from the reverse rotation after it
has stopped.
0 : Initial value
1 : Less effective / 9 : Highly effective
This function sets the magnitude of return force of the needle bar before
the retry motion.
1 : Less return force / 15 : High return force
This function sets the suction motion time of the back-tack solenoid.
50 ms to 300 ms
Function of reverse feed stitching on the way
0 : Function of reverse stitching on the way is not operative.
1 : Function of reverse feed stitching on the way is operative.
Number of stitches of reverse feed stitching on the way.
Effective condition of reverse feed stitching on the way
0 : Function is not operative when the sewing machine stops.
1 : Function is operative when the sewing machine stops.
Thread trimming function by reverse feed stitching on the way
0 : Automatic thread trimming function after completion of reverse feed
stitching on the way is not operative.
1 : Automatic thread trimming after completion of reverse feed stitching
on the way is performed.
Lowest speed by pedal
Sewing speed at the start of sewing (soft-start)(The max. value depends
on the number of rotation of the sewing machine head.)
Ref.
page
21
29
21
21
21
21
22
22
22
22
28
19
23
27
27
27
27
27
*
Indication of
function setting
24
0
25 1
26
0
22
0
27 3
29
250
30
0
31 4
32
0
33 0
35
200
37
800
38
2500
39
30
40
60
41
–21
42 10
43
–51
*
*
*
*
*
*
* Functions with * (asterisk) are those for maintenance. Be very careful of changing the set value.
