JUKI SC-500 - 13 Block Diagram

− 43 −
* A,E: 40016493 PSC UNIT A ASSY
* B: 40016494 PSC UNIT B ASSY
* C: 40016495 PSC UNIT C ASSY
* D: 40018367 PSC UNIT D ASSY
13. BLOCK DIAGRAM
M50
* B: 40018481 E50 COMPLETE
* A,E: 40018482 E50 COMPLETE JUS
* C: 40018483 E50 COMPLETE JE
* D: 40018484 E50 COMPLETE CN
4P
2P
2P
2P
2P
* A,E:
40016522
VOLTAGE SELACT CORD ASSY
40006134
RESISTANCE A ASSY
* A: M6101471AA0 POWER SWITCH A ASM
* B,D: M6101471CA0 POWER SWITCH C ASM
4P
4P
CN41
(OPTIONAL P.C.B. I/F)
CN34
(PEDAL SENSOR)
CN39
(STAND PEDAL)
CN38
(CP-160)
* A,E
CN1
(110V/220V CHANGEOVER)
CN2
(REGERATIVE RESISTANCE)
T3-1
T3-2
T3-3
CN141
CN4
(+5V, EACH CONTROL SIGNAL)
CN3
(VOUT +33Vor+24Vor+12V)
T15-3
T15-1
T15-2
* A,E: 40016465 PWR PCB A ASSY
* B,D: 40016466 PWR PCB B ASSY
* C: 40016467 PWR PCB C ASSY
* C: M6102461DAA
POWER INPUT CABLE CE ASM
* C: 40006139
POWER INPUT CABLE D ASM
* E: 40012009
POWER INPUT CABLE LA ASM
4P4P4P
(MOTOR DRIVE)
20P 12P
20P
4P
4P
30P
40016471
PEDAL SENSOR UNIT C ASSY
* OP:
CP-160 PANEL
9P
9P
4P
7P
2P
2P7P4P
14P
14P 11P
CN140
CN40
(USER EXTENSION SIGNAL)
CN36
(HEAD MAGNET DRIVE)
CN37
(FL)
CN33
(SYNCHRONIZER)
CN32
(HEAD DISCRIMINATION)
CN30
(ENCODER)
40012423
CTL PCB ASSY
CN31 CN35
26P
26P
26P
26P
40016468
I/F CABLE ASSY
40016469
DC POWER SUPPLY CORD ASSY
4P
4P
4P
4P
Symbol
A
B
C
D
E
Destination
JUS
JS
JE
CN
JUS
“* SYMBOL” in the diagram indicates the selective parts for the classified destination.
No mark is used for all destinations. In addition, “*OP:” indicates optional selective parts.
Name of electric equipment complete set
SC500 1/3PHASE 120/240 PFL
SC500 1PHASE 200/240 PFL
SC500 1PHASE 230 PFL CE
SC500 1PHASE 220 PFL CN
SC500 1PHASE 100-120 PFL LA
Part No. of complete set
40016490
40016491
40016492
40018366
40018385
