−29 −
$0 Function of prohibiting compensation stitching operation after turning handwheel by hand
(Function setting No. 91)
This function can select Prohibited/Effective of compensating stitch command after needle position detector
signal is OFF once by turning handwheel by hand after stop of sewing machine.
0 : Effective
1 : Prohibited
$1 Fine adjustment of number of rotations function (Function setting No. 24)
When rotation is transmitted to the sewing machine by means of V belt, and the number of rotations of
machine head and that of the sewing machine do not rotate in a ratio of 1 to 1 due to the uneven pulley
groove or the like and the max. number of rotations of machine head is not gained, compensation can be
added in the range of ± 1.5%.
Setting range : -1.5 to 1.5% <0.1%/step>
+ 1.5%
Number of rotations
(rpm)
– 1.5%
91
1
24
0
