Figure 2: Rear Panel Components
g007818
Power supply
slot 1
Power supply
slot 0
ACE slot
Grounding point
Air filter cover
ESD pointStorage slot
NOTE: Check the parts in the shipment against the items on the packing list. If anything is missing or damaged,
contact your Juniper Networks customer service representative.
Specifications
SRX550 HMSpecification
3.5 in. x 17.5 in. x 18.2 in.
(8.89 cm x 44.45 cm x 46.23 cm)
Dimensions (D x W x H)
21.96 lb (9.96 kg)Chassis weight
85 WAverage power consumption
238 BTU/hrAverage heat dissipation
5% to 90%, noncondensingRelative humidity
Factory-Default Settings
The SRX550 High Memory device is shipped with the following factory-default settings:
Table 1: Security Policies
Policy ActionDestination ZoneSource Zone
permittrusttrust
permituntrusttrust
3
