JVC DLA-HD1 User Manual

2
Preparation
18
Selecting Connecting Devices
z Do not turn on the power until connection is complete.
z The connection procedures differ according to the device used. For details, refer to the instruction manual of the device to be
connected.
z For audio output, connect the device to an amplifier.
z The images may not be displayed depending on the devices and cables to be connected.
z It may not be possible to connect to this unit depending on the dimension of the connector cover of the cables to be
connected.
DVD Recorder DVD Player
Camcorder VCR
To connect via S-video terminal (pP19)
To connect via video terminal (pP19)
To connect RS-232C terminal (for servicing)
To connect via component video terminals (pP20)
To connect via HDMI terminal (pP20)
DLA-HD1D_EN.book Page 18 Tuesday, January 30, 2007 2:54 PM

JVC DLA-HD1 Specifications

General

Projection distance	3.0/6.1 m
Projection technology	DLP
Contrast ratio (typical)	-
Digital zoom	2 x
Focal length range	21.3 - 42.6 mm
Lamp type	UHP
Lamp power	200 W
Light source type	Lamp
RS-232 ports	1
Dimensions (WxDxH)	455 x 172.5 x 418.5 mm
Connectivity technology	Wired
Full HD	Yes
Serial interface type	RS-232
Power consumption (standby)	2.7 W
Market positioning	Home cinema

Weight and Dimensions

Weight	11600 g
