This section shows the communication examples of RS-232C.

Operating command
 Reference command
RS-232C Communication Examples
Type Command Description
Connection check
PC  This unit: 21 89 01 00 00 0A
This unit  PC: 06 89 01 00 00 0A
Checks connection
Power (On)
PC  This unit: 21 89 01 50 57 31 0A
This unit  PC: 06 89 01 50 57 0A
When power is turned on from standby mode
Power (Off)
PC  This unit: 21 89 01 50 57 30 0A
This unit  PC:06890150570A
When power is turned off (standby mode)
from power-on mode
Input (COMP.)
PC  This unit: 21 89 01 49 50 32 0A
This unit  PC: 06 89 01 49 50 0A
When video input is set to component
Remote Control
(MENU)
PC  This unit: 21 89 01 52 43 37 33 32 45 0A
This unit  PC:06890152430A
When the same operation as pressing the
[MENU] button on the remote control is made
Type Command Description
Power (On)
PC  This unit: 3F 89 01 50 57 0A
This unit  PC:06890150 570A
This unit  PC:4089015057310A
When information on power-on mode is
acquired
Input (S-VIDEO)
PC  This unit: 3F 89 01 49 50 0A
This unit  PC:06890149500A
This unit  PC:4089014950300A
When information on S-VIDEO input is
acquired
