JVC DLA-HD1 User Manual

6
52
Others
Specifications
1 D-ILA is the abbreviation for Direct drive Image Light Amplifer.
2 D-ILA devices are manufactured using extremely high-precision technology. Pixel effectiveness is 99.99 %. Only 0.01 % or less of the pixels
are either missing or would remain permanently lit up.
3 HDCP is the abbreviation for High-bandwidth Digital Content Protection system.
The image of HDMI input terminal may not be displayed due to HDCP specification change.
• Design and specifications are subject to change without prior notice.
• Please note that some of the pictures and illustrations may have been abridged, enlarged or contextualized in order to aid comprehension.
Images may differ from the actual product.
Product Name D-ILA Projector
Model Name DLA-HD1
Display Panel/Size
D-ILA device 1 2 /
0.7" (1920 pixels c1080 pixels) c 3 (Total no. of pixels: Approx. 6.22 million)
Projection Lens 2.0x manual zoom lens (1.4: 1 f 2.8: 1) (Zoom/Focus: Manual)
Light-source Lamp 200 W Ultra-high pressure mercury lamp [Part No.: BHL5009-S]
Screen Size Approx. 60" f 200" (Aspect ratio: 16:9)
Projection Distance Approx. 1.8 m f 12.2 m
Color System NTSC, NTSC4.43, PAL, PAL-M, PAL-N, SECAM (Auto/Manual switch)
Analog Video Input Format 480i, 480p, 576i, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50 Hz, 1080i/60 Hz
Digital Video Input Format
480i, 480p, 576i, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50 Hz, 1080i/60 Hz,
1080p/24 Hz, 1080p/50 Hz, 1080p/60 Hz, VGA 60Hz
Resolution 1920 dots c 1080 dots
Input Terminals
Video Input
(VIDEO)
1-line, RCA pin jack c 1
1.0 V(p-p), 75 &, synchronous
S-video Input
(S-VIDEO)
1-line, mini DIN 4 pin c 1
Y: 1.0 V(p-p), 75 &
C: 0.286 V(p-p), 75 & (NTSC); 0.3 V(p-p), 75 & (PAL)
Component Video Input
(COMPONENT)
1-line, RCA pin jack c 3
Y: 1.0 V(p-p), 75 &
C
B
/P
B
, C
R
/P
R
: 0.7 V(p-p), 75 &
HDMI Input
(HDMI 1, HDMI 2)
2-line, HDMI 19 pin c 2 (HDCP compliant) 3
Power Requirements AC 110 V - 240 V 50/60 Hz
Power Consumption 280 W (Standby mode: 2.7 W)
Operation Environment
Temperature: 5 %f35 %
Humidity: 20 % f 80 % (No condensation)
(Storage Temperature: b10 %f60 %)
Installation Height Below 5000 ft (Approx. 1524 m)
Dimensions (Width c Height c Depth)
455 mm c 172.5 mm c 418.5 mm
(17 7/8" c 6 7/8" c 16 1/2")
(Excluding lens and protrusion portion)
Mass 11.6 kg (25.5 lbs)
Accessories (See Page 13)
DLA-HD1D_EN.book Page 52 Tuesday, January 30, 2007 2:54 PM

JVC DLA-HD1 Specifications

General

Projection distance	3.0/6.1 m
Projection technology	DLP
Contrast ratio (typical)	-
Digital zoom	2 x
Focal length range	21.3 - 42.6 mm
Lamp type	UHP
Lamp power	200 W
Light source type	Lamp
RS-232 ports	1
Dimensions (WxDxH)	455 x 172.5 x 418.5 mm
Connectivity technology	Wired
Full HD	Yes
Serial interface type	RS-232
Power consumption (standby)	2.7 W
Market positioning	Home cinema

Weight and Dimensions

Weight	11600 g
