Controls
a •E-Mail Clip Recording Button
[E-MAIL] ...................................... 墌 pg. 60, 61
•Information Button [INFO]................ 墌 pg. 30
b Menu Button [MENU, +, –].................. 墌 pg. 38
c •+, – Button ........................................ 墌 pg. 38
•LCD Monitor Brightness Control
[MONITOR BRIGHT +, –] ................. 墌 pg. 13
d •Power Zoom Ring [T/W].................... 墌 pg. 20
•Shuttle Search Ring [SHUTTLE SEARCH,
3/5] ........................................ 墌 pg. 22
e •Recording Start/Stop Button.............. 墌 pg. 19
•Play/Pause Button [4/9] .................. 墌 pg. 22
f Power Switch [A, M, P, OFF].......... 墌 pg. 14
g Lock Button ......................................... 墌 pg. 14
h Snapshot Button [SNAPSHOT]....... 墌 pg. 27, 52
i •Stop Button [8] ................................. 墌 pg. 22
•Digital Sound Button [D.SOUND]..... 墌 pg. 57
j •Index Button [INDEX] ........... 墌 pg. 30, 57, 71
•Navigation Button [NAVI] ................. 墌 pg. 58
k Set/Select Button [SET/SELECT] ........... 墌 pg. 38
l Battery Release Switch
[BATT.RELEASE] ................................... 墌 pg. 10
m Cassette Open/Eject Switch
[OPEN/EJECT]...................................... 墌 pg. 16
n •Focus Adjustment Button [FOCUS] ... 墌 pg. 54
•Blank Search Button [BLANK] ........... 墌 pg. 23
o VIDEO/MEMORY Switch
[VIDEO/MEMORY].............................. 墌 pg. 14
p •Exposure Button [EXPOSURE] ........... 墌 pg. 55
•Speaker Volume Control
[VOL. +]............................................. 墌 pg. 22
q •Backlight Compensation Button
[BACKLIGHT] .................................... 墌 pg. 56
•Speaker Volume Control
[VOL. –] ............................................. 墌 pg. 22
r Dioptre Adjustment Control ................ 墌 pg. 12
Connectors
The connectors are located beneath the covers.
S Digital Video Connector [DV IN/OUT
(GR-DVP7) or DV OUT (GR-DVP5)]
(i.Link*).................................... 墌 pg. 63, 64, 78
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
T USB (Universal Serial Bus)
Connector............................................ 墌 pg. 78
U S/AV connector ....................... 墌 pg. 24, 62, 74
V Headphone Connector [ ] ................ 墌 pg. 70
No sound is output from the speaker when
headphones are connected to this connector.
Indicators
A Power Lamp [POWER]....................墌 pg. 14, 19
B Tally Lamp ......................................墌 pg. 19, 47
Other Parts
Y LCD Monitor ..................................墌 pg. 13, 20
a Battery Pack Mount ..............................墌 pg. 10
b Speaker ................................................墌 pg. 22
c Grip Belt/Strap Eyelet.............................墌 pg. 6
d Viewfinder............................................墌 pg. 12
e Viewfinder Cleaning Hatch ..................墌 pg. 91
f Cassette Holder Cover..........................墌 pg. 16
g Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
h Stereo Microphone...............................墌 pg. 70
i Info-Shoe
Attach the optional video light/flash/zoom
microphone. Make sure to turn off the power of
the camcorder and the video light/flash/zoom
microphone before attaching and removing
them.
j Lens
k Lens Cover............................................墌 pg. 19
l Grip Belt Eyelet ......................................墌 pg. 6
m Remote Sensor .....................................墌 pg. 66
n Tripod Mounting Socket .......................墌 pg. 13
o Card Cover [MEMORY CARD] ............墌 pg. 17
