ENGLISH 35
OTHER EXTERNAL COMPONENTSOTHER EXTERNAL COMPONENTS
Using the rear view camera
• To connect a rear view camera, see page64 .
• To use a rear view camera, a REVERSE lead
connection is required. (Page 62 )
❏ Settings for the rear view camera
1 Display the <Input> settings screen.
On the Home screen:
2 Display the <Rear Camera> screen.
3
[ON] Displays the picture from the rear view
camera when you shift the gear to the
reverse (R) position.
[OFF] Select this when no camera is
connected
❏ Displaying the rear view camera screen
To display the picture from the rear view camera
The rear view screen is displayed when you shift the
gear to the reverse (R) position.
• To remove the caution message, touch the screen.
To display the picture from the rear view camera
manually
• Only for KW-V420BT /KW-V220BT/KW-V120BT : You
can also display the picture from the rear view
camera by selecting [Camera] on the pop-up
short-cut menu (Page11).
To exit the camera screen
Press HOME on the monitor panel.
• You can also exit the camera screen by touching
the area shown below.
Continued on the next page...
