TROUBLESHOOTING GUIDE
THE COLOR DOES NOT
APPEAR
Is Setting of color
Normal?
No
Yes
Yes
No
Check IC MT5310CHHU and
peripheral circuit.
Is there color signal at
IC MT5310CHHU?
No
Adjust the color.
Is the color signal
received?
Receive the color signal.
Change IC MT5310CHHU.
Yes
