WAVEFORMS

SCALER VIDEO/AUDIO

20µs/div 2ms/div

500mV/div 200mV/div

AV IN PC AUDIO L

10µs/div 2ms/div

200mV/div 200mV/div

PY PC AUDIO R

10µs/div 1ms/div

100mV/div 500mV/div

PR AUDIO OUT L

10µs/div 1ms/div

200mV/div 500mV/div

PB AUDIO OUT R

1ms/div 1ms/div

200mV/div 2V/div

AU AUDIO IN L SPEAKER L

1ms/div 1ms/div

200mV/div 2V/div

AU AUDIO IN R SPEAKER R

NOTE : Main Board Signal Input/Output.
