JVC LT-22HG45E Service Manual

ELECTRICAL REPLACEMENT PARTS LIST
REF. NO.
PART NO.
DESCRIPTION
QUANTITY
REMOCON PCB ASS'Y
*** PCB ***
PCBDA0 X-A3LJ03WDA0P REMOCON PCB ASS'Y CEJ570A 1
*** RESISTORS ***
R7605 X-R803R9101J RC 100 OHM 1/16W HPWGJ101T50 1
*** CAPACITORS ***
C7602 X-CS0PB0PQ6K CC 4.7 UF 6.3V B GRM188B30J475KE18D 1
*** OTHERS ***
CP7601 X-06GG230029 CONNECTOR PCB SIDE A2001WV-3A 1
OS7601 X-077Q038012 REMOTE RECEIVER KSM-603LM2M(OR) 1
LED PCB ASS'Y
*** PCB ***
PCBDT0 X-A3LJ03WDT0P LED PCB ASS'Y CEJ572A 1
*** DIODES ***
*** DIODES ***
D7602 X-0021991050 LED BA36-PUR1DCB549T1/470 1
*** OTHERS ***
CD7602 X-06E8231204 CORD CONNECTOR E8231204 1
*** OTHERS ***
! V7201 X-A3LJ03WFM0P LED MODULE ASS'Y M215HGE-P02-LED OR7A 1
POWER PCB ASS'Y
*** PCB ***
PCB240 X-A3LJ03W240P POWER PCB ASS'Y CEL788A 1
*** RESISTORS ***
R501 X-R002T2562J RC 5.6K OHM 1/2W CR1/2W-SS562JT/B 1
R502 X-R002T4331J RC 330 OHM 1/4W BCS4J0331A10 1
! R503 X-RC31X1126J RC 12M OHM 1W RCR60CT52A126J 1
! R504 X-R8X2R8334J RC 330K OHM 1/8W 1206W8J0334T5E 1
! R505 X-R3K781R27J R,METAL OXIDE 0.27 OHM 1W ERX1FJR27H 1
! R506 X-R803R9333J RC 33K OHM 1/16W HPWG J 333 T50 1
R507 X-R002T4101J RC 100 OHM 1/4W BCS4J0101A10 1
! R510 X-R63881R22J R,FUSE 0.22 OHM 1W RF1CL15AR22J 1
! R511 X-RC31X1224J RC 220K OHM 1W RCR60CT52A224J 1
R512 X-R002T2562J RC 5.6K OHM 1/2W CR1/2W-SS562JT/B 1
R513 X-R803R9221J RC 220 OHM 1/16W HPWGJ221T50 1
R514 X-R803R9330J RC 33 OHM 1/16W HPWG J 330 T50 1
R515 X-R803R9102J RC 1K OHM 1/16W HPWGJ102T50 1
R516 X-R803R9104J RC 100K OHM 1/16W HPWGJ104T50 1
! R518 X-R002T4101J RC 100 OHM 1/4W BCS4J0101A10 1
