3-4(No.YA492)
EXPLODED VIEW PARTS LIST
Ref.No. Part No. Part Name Description Local
1 GA10276-002A-U STAND ASSY
LT-26A70BJ,LT-26A70BU,LT-32A70BJ,LT-32A70BU
1 GA10276-001A-U STAND ASSY
LT-26A70SJ,LT-26A70SU,LT-32A70SJ,LT-32A70SU
1 GA10176-003A-U STAND ASSY
LT-32A70GU
2 QYSPSPD5020ZA SCREW M5 x 20mm(x4)
3 LC12341-008A-U REAR COVER
LT-26A70BJ,LT-26A70BU,LT-26A70SJ,LT-26A70SU
3 LC12396-008A-U REAR COVER
LT-32A70BJ,LT-32A70BU,LT-32A70GU,LT-32A70SJ,LT-32A70SU
4 QYSBSF4012ZA TAP SCREW M4 x 12mm(x8)
5 LC42446-001A SCREW (x3)
6 WJZ0247-001A-E E-HARNESS ASSY POWER P/W-LCD PANEL UNIT
LT-26A70BJ,LT-26A70BU,LT-26A70SJ,LT-26A70SU
6 WJZ0248-001A-E E-HARNESS ASSY POWER P/W-LCD PANEL UNIT
LT-32A70BJ,LT-32A70BU,LT-32A70GU,LT-32A70SJ,LT-32A70SU
7 WJZ0249-001A-E E-HARNESS ASSY
POWER A/F-MAIN CN00A/CN00F
8 LC33650-001A-HK INSULATOR
9 QYSBSF3010ZA TAP SCREW M3 x 10mm(x3)
10 LC42446-001A SCREW (x2)
11 LC13020-002A-U TERMINAL BASE
12 QMPN370-170-JC POWER CORD(EK) 1.7m BLACK
LT-26A70BJ,LT-26A70SJ,LT-32A70BJ,LT-32A70SJ
12 QMPK450-170-JC POWER CORD(EU) 1.7m BLACK
LT-26A70BU,LT-26A70SU,LT-32A70BU,LT-32A70GU,LT-32A70SU
13 WJW0056-001A-E DIGITAL(LVDS) CABLE
LCD PANEL UNIT-MAIN CN0LV2
LT-26A70BJ,LT-26A70BU,LT-26A70SJ,LT-26A70SU
13 WJW0056-002A-E DIGITAL(LVDS) CABLE
LCD PANEL UNIT-MAIN CN0LV2
LT-32A70BJ,LT-32A70BU,LT-32A70GU,LT-32A70SJ,LT-32A70SU
14 QLD0443-001-JUK LCD PANEL UNIT
LT-26A70BJ,LT-26A70BU,LT-26A70SJ,LT-26A70SU
14 QLD0444-001-JUK LCD PANEL UNIT
LT-32A70BJ,LT-32A70BU,LT-32A70GU,LT-32A70SJ,LT-32A70SU
15 LC12340-006B-U FRONT PANEL
LT-26A70BJ
15 LC12340-006A-U FRONT PANEL
LT-26A70BU
15 LC12340-005B-U FRONT PANEL
LT-26A70SJ
15 LC12340-005A-U FRONT PANEL
LT-26A70SU
15 LC12395-006B-U FRONT PANEL
LT-32A70BJ
15 LC12395-006A-U FRONT PANEL
LT-32A70BU
15 LC12395-007B-U FRONT PANEL
LT-32A70GU
15 LC12395-005B-U FRONT PANEL
LT-32A70SJ
15 LC12395-005A-U FRONT PANEL
LT-32A70SU
16 LC12467-004A-U KNOB ASSY
LT-26A70BJ,LT-26A70SJ,LT-32A70BJ,LT-32A70GU,LT-32A70SJ
16 LC12467-003A-U KNOB ASSY
LT-26A70BU,LT-26A70SU,LT-32A70BU,LT-32A70SU
17 WJZ0250-001A-E E-HARNESS ASSY
CONTROL R/IR U-MAIN CN00R/CN00U
18 LC42247-007A LED PLATE
19 LC41852-001B JVC MARK ASSY
20 QAS0489-001 SPEAKER (x2)
21 LC22243-001A-U SPEAKER HOLDER
22 LC22243-002A-U SPEAKER HOLDER
23 LC33649-001A-JK BACK BRACKET (x2)
50 SFT-1051A-U2 MAIN PWB
LT-26A70BJ,LT-26A70BU,LT-26A70SJ,LT-26A70SU
50 SFT-1052A-U2 MAIN PWB
LT-32A70BJ,LT-32A70BU,LT-32A70GU,LT-32A70SJ,LT-32A70SU
51 SFT-9051A-U2 POWER PWB
52 SFT-7251A-U2 CONTROL PWB
53 SFT-8951A-U2 IR PWB
