3-10(No.YA492)
CONTROL P.W. BOARD ASS'Y (SFT-7251A-U2)
R335 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R336 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R337 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R338 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R339 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R340 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R341 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R342 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R343 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R344 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R601 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R602 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R603 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R604 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R607 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R608 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R609 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R610 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R611 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R612 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R613 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R614 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R615 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R616 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R618 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R626 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
RA92 NRZ0065-101X NET RESISTOR 100
Ω
1/16W J
RA93 NRZ0065-101X NET RESISTOR 100
Ω
1/16W J
RA166 NRZ0052-150W NET RESISTOR 15
Ω
1/32W J
RA167 NRZ0052-150W NET RESISTOR 15
Ω
1/32W J
RA168 NRZ0052-150W NET RESISTOR 15
Ω
1/32W J
RA169 NRZ0052-330W NET RESISTOR 33
Ω
1/32W J
RA170 NRZ0052-150W NET RESISTOR 15
Ω
1/32W J
RA171 NRZ0052-330W NET RESISTOR 33
Ω
1/32W J
RA172 NRZ0052-150W NET RESISTOR 15
Ω
1/32W J
RA173 NRZ0052-150W NET RESISTOR 15
Ω
1/32W J
RA174 NRZ0052-150W NET RESISTOR 15
Ω
1/32W J
RA175 NRZ0052-150W NET RESISTOR 15
Ω
1/32W J
RA176 NRZ0052-150W NET RESISTOR 15
Ω
1/32W J
RA177 NRZ0052-150W NET RESISTOR 15
Ω
1/32W J
RA253 NRZ0065-101X NET RESISTOR 100
Ω
1/16W J
RA254 NRZ0065-101X NET RESISTOR 100
Ω
1/16W J
L1 NQR0383-002X CHOKE COIL
L2 NQR0383-002X CHOKE COIL
L3 NQR0383-002X CHOKE COIL
L4 NQR0383-002X CHOKE COIL
L5 NQR0383-002X CHOKE COIL
L7 NQL382M-2R2X COIL 2.2uH M
L8 NQL382M-2R2X COIL 2.2uH M
L9 NQL382M-2R2X COIL 2.2uH M
L10 NQL382M-2R2X COIL 2.2uH M
L11 NQL382M-2R2X COIL 2.2uH M
L12 NQL382M-2R2X COIL 2.2uH M
L13 NQLE82M-1R0X COIL 1uH M
L14 NQLE82M-100X COIL 10uH M
L15 NQLE82M-100X COIL 10uH M
L16 NQLE82M-100X COIL 10uH M
L17 NQLE82M-100X COIL 10uH M
L18 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L19 NQL953J-3R3X COIL 3.3uH J
L20 NQL953J-3R3X COIL 3.3uH J
L21 NQL953J-3R3X COIL 3.3uH J
L22 NQL953J-3R3X COIL 3.3uH J
L23 NQL953J-3R3X COIL 3.3uH J
L24 NQL953J-3R3X COIL 3.3uH J
L25 NQL953J-3R3X COIL 3.3uH J
L26 NQL953J-3R3X COIL 3.3uH J
L27 NQL953J-3R3X COIL 3.3uH J
L28 NQL953J-3R3X COIL 3.3uH J
L32 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L33 NQL71EM-150X COIL 15uH M
L36 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L37 NQL093M-220X COIL 22uH M
L38 NQL093M-180X COIL 18uH M
L39 NQLE82M-100X COIL 10uH M
L40 NQL71EM-150X COIL 15uH M
L41 NQL71EM-150X COIL 15uH M
L601 NQLF3EM-330X COIL 33uH M
L602 NQLF3EM-330X COIL 33uH M
L603 NQLF3EM-330X COIL 33uH M
L604 NQLF3EM-330X COIL 33uH M
FB1 NQR0155-003X FERRITE CORE
FB2 NQR0155-003X FERRITE CORE
FB3 NQR0155-003X FERRITE CORE
FB4 NQR0155-003X FERRITE CORE
FB5 NQR0155-003X FERRITE CORE
FB6 NQR0155-003X FERRITE CORE
FB7 NQR0155-003X FERRITE CORE
Ref No. Part No. Part Name Description Local
FB8 NQR0155-003X FERRITE CORE
FB10 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
FB12 NQR0155-003X FERRITE CORE
FB13 NQR0413-002X FERRITE BEADS
FB14 NQR0413-003X FERRITE BEADS
FB15 NQR0413-003X FERRITE BEADS
FB16 NQR0413-003X FERRITE BEADS
FB17 NQR0413-003X FERRITE BEADS
FB18 NQR0413-003X FERRITE BEADS
FB19 NQR0155-003X FERRITE CORE
FB20 NQR0155-003X FERRITE CORE
FB21 NQR0155-003X FERRITE CORE
FB22 NQR0155-003X FERRITE CORE
FB23 NQR0155-003X FERRITE CORE
FB24 NQR0155-003X FERRITE CORE
FB25 NQR0413-002X FERRITE BEADS
FB26 NQR0413-003X FERRITE BEADS
FB27 NQR0413-003X FERRITE BEADS
FB28 NQR0413-003X FERRITE BEADS
FB29 NQR0413-003X FERRITE BEADS
FB30 NQR0413-003X FERRITE BEADS
FB31 NQR0155-003X FERRITE CORE
FB32 NQR0413-003X FERRITE BEADS
FB33 NQR0413-003X FERRITE BEADS
FB34 NQR0413-003X FERRITE BEADS
FB35 NQR0413-003X FERRITE BEADS
FB36 NQR0413-003X FERRITE BEADS
FB37 NQR0413-003X FERRITE BEADS
FB38 NQR0155-003X FERRITE CORE
FB39 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
FB40 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
FB41 NQR0155-003X FERRITE CORE
FB43 NQR0413-003X FERRITE BEADS
FB44 NQR0413-003X FERRITE BEADS
FB45 NQR0413-003X FERRITE BEADS
FB46 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
FB50 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
FB52 NQR0413-003X FERRITE BEADS
FB54 NQR0599-004X FERRITE BEADS
FB55 NQR0599-004X FERRITE BEADS
FB61 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
FB62 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
FB63 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
FB64 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
FB65 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
J1 QNZ0465-001 21P CONNECTOR EXT-1/EXT-2
J3 QNN0798-001 PIN JACK EXT-3/EXT-4
J5 NNZ0117-001 CONNECTOR DIGITAL IN
TU1 QAU0488-001 TUNER
X1 NAX0920-001X CRYSTAL 28.322000MHz
X2 QAX0532-001 CRYSTAL 10.000MHz
X3 QAX0918-001Z CRYSTAL 18.432MHz
Ref No. Part No. Part Name Description Local
D7001 UDZW5.6B-X Z DIODE
D7002 UDZW5.6B-X Z DIODE
D7003 UDZW5.6B-X Z DIODE
C7001 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7002 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R7001 NRSA63J-330X MG RESISTOR 33
Ω
1/16W J
R7002 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R7003 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R7004 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R7005 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R7006 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
J7001 QNS0097-001 HEADPHONE JACK HEADPHONE
K7008 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
S7001 QSW1131-001Z TACT SWITCH POWER
S7002 QSW1131-001Z TACT SWITCH TV/AV
S7003 QSW1131-001Z TACT SWITCH MENU/OK
S7004 QSW1131-001Z TACT SWITCH VOL+
S7005 QSW1131-001Z TACT SWITCH VOL-
S7006 QSW1131-001Z TACT SWITCH CH+
S7007 QSW1131-001Z TACT SWITCH CH-
Ref No. Part No. Part Name Description Local
