JVC LT-32A70BU Service Manual

3-6(No.YA492)
PRINTED WIRING BOARD PARTS LIST [LT-26A70BJ, LT-26A70BU, LT-26A70SJ, LT-26A70SU]
MAIN P.W. BOARD ASS'Y (SFT-1051A-U2)
 Ref No. Part No. Part Name Description Local
IC2 EDD1232AABH-6B IC
IC3 M30620SPGP-U5C IC(MCU)
IC5 39VF16827CEKD03 IC(MICRO C ROM)
IC6 S-80829CNNB-G-W IC
IC7 ATE64-26A70BJ IC (SERVICE)
IC8 ATF02-26A70BJ IC (SERVICE)
IC9 BA7657F-X IC
IC11 MSP3410GQAB8V3 IC
IC13 BH3547F-X IC
IC14 MP2363DN-X IC
IC15 MM1661JH-X IC
IC16 MM1663DH-X IC
IC17 MM1663DH-X IC
IC18 PQ025EN02Z-X IC
IC19 MM1663DH-X IC
IC20 BA80BC0FP-X IC
IC21 UDA1334BT/N2-X Z DIODE
IC22 MP2363DN-X IC
IC23 MP2363DN-X IC
IC601 TPA3100D2PHP-W IC
Q1 SSM3K17FU-X MOS FET
Q2 RT1N441C-X TRANSISTOR
Q3 RT1N441C-X TRANSISTOR
Q4 2SK1228-X MOS FET
Q5 2SK1228-X MOS FET
Q6 SSM3K17FU-X MOS FET
Q7 SSM3K17FU-X MOS FET
Q8 RT1N441C-X TRANSISTOR
Q9 2SC3928A/QR/-X TRANSISTOR
Q10 2SC3928A/QR/-X TRANSISTOR
Q11 2SC3928A/QR/-X TRANSISTOR
Q12 2SC3928A/QR/-X TRANSISTOR
Q13 2SC3928A/QR/-X TRANSISTOR
Q14 2SC3928A/QR/-X TRANSISTOR
Q15 2SC3928A/QR/-X TRANSISTOR
Q16 2SC3928A/QR/-X TRANSISTOR
Q17 2SC3928A/QR/-X TRANSISTOR
Q18 2SC3928A/QR/-X TRANSISTOR
Q21 RT1N140C-X DIGI TRANSISTOR
Q22 2SA1530A/QR/-X TRANSISTOR
Q26 2SC3928A/QR/-X TRANSISTOR
Q27 2SC3928A/QR/-X TRANSISTOR
Q28 2SC3928A/QR/-X TRANSISTOR
Q29 RT1P441C-X DIGI TRANSISTOR
Q30 SSM3K17FU-X MOS FET
Q31 RT4N430C-X DIGI TRANSISTOR
Q32 RT4N430C-X DIGI TRANSISTOR
Q33 2SA1530A/QR/-X TRANSISTOR
Q34 RT4N430C-X DIGI TRANSISTOR
Q35 RT4N430C-X DIGI TRANSISTOR
Q36 2SA1530A/QR/-X TRANSISTOR
Q37 2SA1530A/QR/-X TRANSISTOR
Q38 RT1N430C-X TRANSISTOR
Q39 2SA1530A/QR/-X TRANSISTOR
Q603 2SC3928A/QR/-X TRANSISTOR
Q604 2SC3928A/QR/-X TRANSISTOR
Q605 2SC3928A/QR/-X TRANSISTOR
Q607 2SA1530A/QR/-X TRANSISTOR
D1 1SS355W-X DIODE
D2 UDZW4.7B-X Z DIODE
D3 UDZW4.7B-X Z DIODE
D4 UDZW4.7B-X Z DIODE
D5 UDZW4.7B-X Z DIODE
D6 UDZW8.2B-X Z DIODE
D7 UDZW8.2B-X Z DIODE
D8 UDZW4.7B-X Z DIODE
D9 UDZW4.7B-X Z DIODE
D10 UDZW10B-X Z DIODE
D11 UDZW5.6B-X Z DIODE
D12 UDZW5.6B-X Z DIODE
D13 UDZW5.6B-X Z DIODE
D14 UDZW8.2B-X Z DIODE
D15 UDZW8.2B-X Z DIODE
D16 UDZW4.7B-X Z DIODE
D17 UDZW4.7B-X Z DIODE
D18 UDZW10B-X Z DIODE
D19 UDZW5.6B-X Z DIODE
D20 UDZW5.6B-X Z DIODE
D21 UDZW5.6B-X Z DIODE
D22 UDZW8.2B-X Z DIODE
D23 UDZW8.2B-X Z DIODE
D24 UDZW8.2B-X Z DIODE
D25 UDZW8.2B-X Z DIODE
D26 UDZW8.2B-X Z DIODE
D27 UDZW8.2B-X Z DIODE
D28 UDZW5.6B-X Z DIODE
D29 UDZW5.6B-X Z DIODE
D30 UDZW4.7B-X Z DIODE
D31 UDZW4.7B-X Z DIODE
D32 UDZW5.6B-X Z DIODE
D42 1SS355W-X DIODE
D43 1SS355W-X DIODE
D44 1SS355W-X DIODE
D45 EC31QS04-X SB DIODE
D50 1SS355W-X DIODE
D53 EC31QS04-X SB DIODE
D54 RB501V-40-X SB DIODE
D55 1SS355W-X DIODE
D56 1SS355W-X DIODE
D58 EC31QS04-X SB DIODE
D59 EC31QS04-X SB DIODE
D60 RB501V-40-X SB DIODE
D63 1SS355W-X DIODE
D65 EC21QS10-X SB DIODE
D66 EC21QS10-X SB DIODE
D301 1SS355W-X DIODE
D302 1SS355W-X DIODE
D303 1SS355W-X DIODE
D601 1SS355W-X DIODE
D602 1SS355W-X DIODE
D603 1SS355W-X DIODE
D604 1SS355W-X DIODE
C1 NDC31HJ-2R0X C CAPACITOR 2pF 50V J
C2 NDC31HJ-2R0X C CAPACITOR 2pF 50V J
C9 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C10 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C11 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C12 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C14 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C15 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C16 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C17 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C18 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C19 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C20 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C21 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C22 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C23 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C24 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C25 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C26 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C27 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C28 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C29 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C30 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C31 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C32 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C33 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C34 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C35 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C36 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C37 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C38 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C39 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C40 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C41 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C42 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C43 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C44 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C45 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C46 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C47 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C48 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C49 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C50 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C51 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C52 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C53 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C54 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C55 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C56 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C58 NDC31HJ-101X C CAPACITOR 100pF 50V J
C59 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C60 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C61 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C62 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C63 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C64 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C65 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Ref No. Part No. Part Name Description Local
