(No.YA492)3-11
IR P.W. BOARD ASS'Y (SFT-8951A-U2)
POWER P.W. BOARD ASS'Y (SFT-9051A-U2)
Ref No. Part No. Part Name Description Local
IC8001 KSM-2013TC2EL IR DETECT UNIT
Q8001 2SC3928A/QR/-X TRANSISTOR
D8001 HLMP-NS30-J0000 LED POWER
D8002 UDZW5.6B-X Z DIODE
C8001 NCB31CK-102X C CAPACITOR 1000pF 16V K
C8002 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C8003 NCB31CK-104X C CAPACITOR 0.1uF 16V K
R8001 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R8002 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R8003 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8004 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
K8001 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K8002 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K8003 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K8004 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
Ref No. Part No. Part Name Description Local
IC9201 MIP2C20MSSCF IC
IC9501 STR-X6768N-F2 IC
Q9501 2SC3928A/QR/-X TRANSISTOR
Q9502 RT1N241C-X DIGI TRANSISTOR
Q9503 2SC3928A/QR/-X TRANSISTOR
Q9505 2SC3928A/QR/-X TRANSISTOR
D9001 TS25P05G-C2 BRIDGE DIODE
D9203 EG01C-T2 SI DIODE
D9204 SSPX-66-W SI DIODE
D9205 UTCTL431-T IC
D9206 EC21QS10-X SB DIODE
D9215 MA8330/M/-X Z DIODE
D9216 MA8150/M/-X Z DIODE
D9217 MA8150/M/-X Z DIODE
D9501 UDZW5.1B-X SB DIODE
D9502 MTZJ33B-T2 Z DIODE
D9503 1SS355W-X DIODE
D9504 RF101L2S-X SI DIODE
D9505 RF101L2S-X SI DIODE
D9506 SARS01-T2 FR DIODE
D9507 SARS01-T2 FR DIODE
D9508 FR105GT-T3 SI DIODE
D9509 RL2Z-LFC4 SI DIODE
D9511 FMX-G22S SI DIODE
D9512 FMX-G22S SI DIODE
D9513 FMX-G22S SI DIODE
D9514 FR105GT-T3 SI DIODE
D9515 UTCTL431-T IC
D9516 MTZJ16B-T2 Z DIODE
D9517 MTZJ16B-T2 Z DIODE
D9518 1SS355W-X DIODE
D9519 UDZW3.0B-X Z DIODE
D9520 1SS355W-X DIODE
D9522 FMX-G22S SI DIODE
C9001 QFZ9084-105 MPP CAPACITOR 1uF
C9002 QFZ9084-105 MPP CAPACITOR 1uF
C9003 QCZ9078-222 C CAPACITOR 2200pF AC250V M
C9004 QCZ9078-222 C CAPACITOR 2200pF AC250V M
C9005 QCZ9078-222 C CAPACITOR 2200pF AC250V M
C9007 QCZ9071-102 C CAPACITOR 1000pF AC400V M
C9008 QCZ9071-102 C CAPACITOR 1000pF AC400V M
C9205 QFP32JK-222 PP CAPACITOR 2200pF 630V K
C9206 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9207 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9208 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9209 QCZ9071-102 C CAPACITOR 1000pF AC400V M
C9210 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9211 QECR1VM-477Z E CAPACITOR 470uF 35V M
C9212 QEHR1AM-337Z E CAPACITOR 330uF 10V M
C9501 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9502 QEHR1HM-225Z E CAPACITOR 2.2uF 50V M
C9503 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9504 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9505 NCB31HK-272X C CAPACITOR 2700pF 50V K
C9506 QCZ0340-821 C CAPACITOR 820pF 2kV K
C9507 QEZ0739-337 E CAPACITOR 330uF
C9508 QFP32JK-332 PP CAPACITOR 3300pF 630V K
C9509 QEHR1HM-336Z E CAPACITOR 33uF 50V M
C9512 QCZ9071-471 C CAPACITOR 470pF AC400V K
C9514 QCB31HK-471Z C CAPACITOR 470pF 50V K
C9518 QECR2AM-156Z E CAPACITOR 15uF 100V M
C9519 QEZ0849-128 E CAPACITOR 1200uF
C9520 QEZ0849-128 E CAPACITOR 1200uF
C9521 QEZ0849-128 E CAPACITOR 1200uF
C9522 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9523 QEZ0848-188 E CAPACITOR 1800uF
C9526 QECR1EM-687Z E CAPACITOR 680uF 25V M
C9527 QECR1EM-227Z E CAPACITOR 220uF 25V M
C9528 QECR1VM-227Z E CAPACITOR 220uF 35V M
C9529 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9530 NCB31HK-222X C CAPACITOR 2200pF 50V K
R9001 QRZ0107-474Z C RESISTOR 470k
Ω
1/2W K
R9205 QRE121J-224Y C RESISTOR 220k
Ω
1/2W J
R9206 QRE121J-101Y C RESISTOR 100
Ω
1/2W J
R9207 NRSA63J-394X MG RESISTOR 390k
Ω
1/16W J
R9208 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9209 QRZ9046-685Z C RESISTOR 6.8M
Ω
1/2W K
R9210 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R9211 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9212 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9213 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9214 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R9215 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9216 NRS12BJ-221W MG RESISTOR 220
Ω
1/2W J
R9501 NRS12BJ-564W MG RESISTOR 560k
Ω
1/2W J
R9502 NRS12BJ-564W MG RESISTOR 560k
Ω
1/2W J
R9503 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9504 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9505 QRK126J-101X UNF C RESISTOR 100
Ω
1/2W J
R9506 QRT029J-R27 MF RESISTOR 0.27
Ω
2W J
R9507 QRT029J-R27 MF RESISTOR 0.27
Ω
2W J
R9508 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9509 QRL039J-220 OMF RESISTOR 22
Ω
3W J
R9510 QRE121J-564Y C RESISTOR 560k
Ω
1/2W J
R9512 QRE121J-220Y C RESISTOR 22
Ω
1/2W J
R9513 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9514 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9515 QRG01GJ-821 OMF RESISTOR 820
Ω
1W J
R9517 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R9518 NRSA63D-273X MG RESISTOR 27k
Ω
1/16W D
R9519 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R9520 NRSA63D-332X MG RESISTOR 3.3k
Ω
1/16W D
R9521 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9525 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R9526 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9527 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9528 QRL029J-182 OMF RESISTOR 1.8k
Ω
2W J
R9529 QRL029J-104 OMF RESISTOR 100k
Ω
2W J
R9531 NRS12BJ-102W MG RESISTOR 1k
Ω
1/2W J
R9532 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R9533 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9534 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
L9001 QQR1764-001 CHOKE COIL
L9201 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L9502 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L9503 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L9504 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
T9202 QQS0381-001 SW TRANSF
T9501 QQS0391-001 SW TRANSF
CP9201 QMFZ052-2R0Z-E FUSE 2A
CP9501 QMFZ049-5R0Z-E FUSE 5A 125V
CP9503 ICP-N70-T IC PROTECTOR 2.5A
CP9504 ICP-N70-T IC PROTECTOR 2.5A
CP9505 ICP-N70-T IC PROTECTOR 2.5A
CP9506 QMFZ043-5R0Z-J1 FUSE 5A AC250V
F9001 QMF5AD2-6R3-J1 FUSE 6.3A AC250V
K9512 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9513 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9514 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9515 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
LF9001 QQR1514-001 LINE FILTER
LF9002 QQR1281-004 LINE FILTER
LF9003 QQR1514-001 LINE FILTER
PC9202 PS2581AL1/QW/ PHOTO COUPLER
PC9501 PS2581AL1/QW/ PHOTO COUPLER
PC9502 PS2581AL1/QW/ PHOTO COUPLER
VA9001 QAF0060-621 VARISTOR 620V
Ref No. Part No. Part Name Description Local
