4
How to attach the stand
NOTE:
• Unplug the AC cord from the AC INPUT terminal.
• Before beginning this process, assure that TV is laid on a clean, safe, and cushioned space to avoid any
damage to the unit.
• Do not touch or press the TV-screen, glass might break under pressure.
• Be sure to follow the instructions. Insufficient tightening or incorrect installation of the stand will not
support your unit correctly, and could result in damage or injury from tip-over.
1) Place the TV on its front onto a table.
2) Align the stand’s bottom-plate (supplied) as seen here.
It will fit in only one direction.
3) Hold the unit and attach the stand and frame stand (LT-32A4/LT-40Z40) slowly. Finally secure the
bottom-plate with screws (included).
NOTE:
To detach the stand, perform these steps in
reverse order.
Dismantling the base
For wall mounting, the base must be dismantled.
To do this, remove screws (J, see page 8) from the
back. Take off the stand and frame stand entirely.
•
LT-32A4 LT-40Z40
LT-32G4/LT-32G40
Warning (LT-32A4/LT-32G4/LT-32G40)
To prevent injury, which could be expected
due to an eventual fall, the TV must be fixed to
the ground according to instruction (see right
image).
Fix to the appropriate ground with the supplied
screw.
NOTE:
There is no liability for any damage to the
ground.
Certain models have two fixing lugs at the rear
of the stand. Rotate them out and fasten them
to the support surface with supplied screws.
•
•
LT-32A4
LT-32G4/LT-32G40
