(No.YA422)3-7
EXPLODED VIEW -2
CARD PWB BRACKET
BOTTOM FRAME
TOP FRAME
MAIN BASE
FRONT
160
159
208
156
156
155
156
158
156
157
156
156
158
207
161
152
153
151
154
