3-26(No.YA422)
REMOTE CONTROL UNIT PARTS LIST (RM-C1855-1C)
PACKING PARTS LIST
L6502 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L6521 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
L6522 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
L6523 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
L6531 NQR0199-007X FERRITE BEADS
L6701 NQR0413-003X FERRITE BEADS
L6911 NQR0499-001X FERRITE BEADS
L6912 NQR0499-001X FERRITE BEADS
L6922 NQL79GM-220X COIL 22uH M
L6923 NQL79GM-220X COIL 22uH M
L6924 NQL79GM-220X COIL 22uH M
L6925 NQL79GM-220X COIL 22uH M
L6931 NQR0499-001X FERRITE BEADS
L7301 NQR0489-002X FERRITE BEADS
L7302 NQR0489-002X FERRITE BEADS
L7303 NQL092K-4R7X COIL 4.7uH K
L7304 NQL092K-4R7X COIL 4.7uH K
L7305 NQL092K-4R7X COIL 4.7uH K
L7306 NQL092K-4R7X COIL 4.7uH K
L7307 NQL092K-4R7X COIL 4.7uH K
L7308 NQL092K-4R7X COIL 4.7uH K
L7309 NQL092K-4R7X COIL 4.7uH K
L7310 NQL092K-4R7X COIL 4.7uH K
L7311 NQL092K-4R7X COIL 4.7uH K
L7312 NQL092K-4R7X COIL 4.7uH K
L7313 NQL092K-4R7X COIL 4.7uH K
L7314 NQR0489-002X FERRITE BEADS
L7315 NQL092K-4R7X COIL 4.7uH K
L7316 NQL092K-4R7X COIL 4.7uH K
L7501 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L7502 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L9001 NQLC8CM-150X COIL 15uH M
L9201 NQLC8CM-150X COIL 15uH M
CN001 QGF0508C2-50W CONNECTOR FFC/FPC (1-50)
CN002 QGF0508C2-40W CONNECTOR FFC/FPC (1-40)
J8501 NNZ0117-001 CONNECTOR DIGITAL IN-1
J8502 NNZ0117-001 CONNECTOR DIGITAL IN-2
K6250 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
Ref No. Part No. Part Name Description Local
K6261 NQR0489-002X FERRITE BEADS
K6263 NQR0489-002X FERRITE BEADS
K6264 NQR0489-002X FERRITE BEADS
K6265 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6266 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6267 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6268 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6272 NQR0499-001X FERRITE BEADS
K6401 NQR0499-001X FERRITE BEADS
K6402 NQR0499-001X FERRITE BEADS
K6403 NQR0499-001X FERRITE BEADS
K6404 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6405 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6921 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7028 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K7031 NQR0470-007X EMI FILTER 2200pF 50V
K7032 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7033 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7034 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7202 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K7211 NQR0499-002X FERRITE BEADS
K7302 NQR0389-003X FERRITE BEADS
K7308 NRSA02J-390X MG RESISTOR 39
Ω
1/10W J
K7501 NQR0413-002X FERRITE BEADS
K7504 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
LC6215 NQR0470-007X EMI FILTER 2200pF 50V
LC6216 NQR0470-007X EMI FILTER 2200pF 50V
LC6501 NQR0479-001X EMI FILTER
LC7505 NQR0483-005X EMI FILTER 100uF 25V Z
LC7507 NQR0498-001X EMI FILTER
LC7508 NQR0498-001X EMI FILTER
LC7509 NQR0498-001X EMI FILTER
LC9301 NQR0470-003X EMI FILTER 100pF 50V
LC9303 NQR0483-005X EMI FILTER 100uF 25V Z
LC9305 NQR0483-005X EMI FILTER 100uF 25V Z
LC9306 NQR0483-005X EMI FILTER 100uF 25V Z
LC9307 NQR0483-005X EMI FILTER 100uF 25V Z
X6250 NAX0580-001X CXO 27.0000MHz
X7001 NAX0669-001X C RESONATOR 6.000MHz
X7309 NAX0618-001X CRYSTAL 6.000MHz
Ref No. Part No. Part Name Description Local
Ref.No. Part No. Part Name Description Local
10032-0023000 BATTERY COVER
Ref.No. Part No. Part Name Description Local
001 GG20120-001A-H PACKING CASE TOP
002 LC32958-001A JOINT (x4)
003 GG20121-001A-H PACKING CASE BOTTOM
004 GG10413-001B-H CUSHION ASSY 4pcs in 1set
005 CP30966-001-H POLY BAG
006 LC22023-001A-H ACCESSORY BOX
007 GG30097-004A-H POLY BAG
008 QAM0028-001 MATCHING BOX LT-Z40SX6
009 ------------ BATTERY AAA/R03 TYPE(x2)
011 QAM0060-002 CONVERSION PLUG LT-Z40SX6
012 LCT2028-001A-H INST BOOK English
013 LCT2029-001A-H INST BOOK Arabic/French/Persian/Russian/Traditional Chinese LT-Z40SX6,LT-Z40SX6S
014 LCT2117-001A-H INST BOOK Ukrainian LT-Z40SX6
015 ------------ WARRANTY CARD BT-56016-1H LT-Z40SX6A
016 ------------ WARRANTY CARD BT-56017-1H LT-Z40SX6A
017 RM-C1855-1C REMOTE CONTROL UNIT
018 QPA01002305 POLY BAG 10cm x 23cm LT-Z40SX6A
To Next Page
