(No.YA422)3-21
PRINTED WIRING BOARD PARTS LIST [LT-Z40SX6/A,LT-Z40SX6/S]
ANALOG P.W. BOARD ASS'Y (SFL-1232A-H2)
REFER TO PARTS LIST IN PAGE 3-8 FOR THIS P.W. BOARD.
D-AMP P.W. BOARD ASS'Y (SFL-6231A-H2)
REFER TO PARTS LIST IN PAGE 3-11 FOR THIS P.W. BOARD.
SW P.W. BOARD ASS'Y (SFL-7205A-H2)
REFER TO PARTS LIST IN PAGE 3-12 FOR THIS P.W. BOARD.
LED P.W. BOARD ASS'Y (SFL-8709A-H2)
REFER TO PARTS LIST IN PAGE 3-12 FOR THIS P.W. BOARD.
MAIN POWER P.W. BOARD ASS'Y (SFL-9049A-H2)
REFER TO PARTS LIST IN PAGE 3-12 FOR THIS P.W. BOARD.
DC-DC P.W. BOARD ASS'Y (SFL-9148A-H2)
REFER TO PARTS LIST IN PAGE 3-14 FOR THIS P.W. BOARD.
SUB POWER P.W. BOARD ASS'Y (SFL-9709A-H2)
REFER TO PARTS LIST IN PAGE 3-14 FOR THIS P.W. BOARD.
DIGITAL P.W. BOARD ASS'Y (SFL0D352A-H2)
 Ref No. Part No. Part Name Description Local
IC6001 JCC5060 IC
IC6002 SN74LVC1G08V-X IC
IC6101 EDD1232AAFA-6B IC
IC6102 SC2595STRT-X IC
IC6250 UPC5702GS-027-X IC
IC6251 R1170H331B-X IC
IC6301 SN74AHCT1G08V-X IC
IC6302 SN74AHCT1G08V-X IC
IC6401 ISL98001CQZ-140 IC
IC6402 R1170H331B-X IC
IC6502 THC63LVDM83R-W IC
IC6724 S-80928CLNB-G-W IC
IC7033 CD74HC4094PW-X IC
IC7036 ADC081S021CIS-X IC
IC7038 SN74LVC2G17KE-X ZC
IC7201 39VF800A71EKD16 IC(MICRO C ROM)
IC7203 M12L16161A-7TG IC
IC7204 S-80928CLNB-G-W IC
IC7205 SN74LV00APW-X IC
IC7301 SDA6000-B12 IC
IC7303 K4S641632K-UC75 IC
IC7304 CD74HC4053PW-X IC
IC7305 MM1689CH-X IC
IC7306 S-80928CLNB-G-W IC
IC7602 ATF32-Z40SX6 IC (SERVICE)
IC7606 MM1671XN-X IC
IC9001 MP2263DN-C053-X IC
IC9101 MM1662FT-X IC
IC9201 MP2263DN-C053-X IC
IC9301 MM1701CH-X IC
Q6202 2SA1530A/QR/-X TRANSISTOR
Q6203 2SA1022/BC/-X TRANSISTOR
Q6204 2SA1022/BC/-X TRANSISTOR
Q6205 2SA1022/BC/-X TRANSISTOR
Q6206 2SA1022/BC/-X TRANSISTOR
Q6211 2SC3837K/NP/-X TRANSISTOR
Q6212 2SC3837K/NP/-X TRANSISTOR
Q6213 2SC3837K/NP/-X TRANSISTOR
Q6214 2SC3837K/NP/-X TRANSISTOR
Q6250 2SC3928A/QR/-X TRANSISTOR
Q6251 2SC3928A/QR/-X TRANSISTOR
Q6301 2SA1530A/QR/-X TRANSISTOR
Q6302 HN1C01F/Y/-X PAIR TRANSISTOR
Q6303 2SA1530A/QR/-X TRANSISTOR
Q6304 HN1C01F/Y/-X PAIR TRANSISTOR
Q6501 2SC3928A/QR/-X TRANSISTOR
Q6502 2SC3928A/QR/-X TRANSISTOR
Q7032 UN2113-X TRANSISTOR
Q7033 UN2113-X TRANSISTOR
Q7034 UN2113-X TRANSISTOR
Q7035 UN2113-X TRANSISTOR
Q7201 2SC3928A/QR/-X TRANSISTOR
Q7301 2SC2412K/QR/-X TRANSISTOR
Q9501 UN2213-X DIGI TRANSISTOR
Q9502 2SC3928A/QR/-X TRANSISTOR
Q9503 2SC3928A/QR/-X TRANSISTOR
D6301 MA111-X SI DIODE
D6302 MA111-X SI DIODE
D6503 1SS355W-X SI DIODE
D7032 1SS355W-X SI DIODE
D7301 RB501V-40-X SB DIODE
D9001 EC30HA03L-X SB DIODE
D9002 EC30HA03L-X SB DIODE
D9003 PTZ3.9B-X Z DIODE
D9201 EC30HA03L-X SB DIODE
D9202 EC30HA03L-X SB DIODE
D9203 PTZ3.9B-X Z DIODE
D9204 1SS355W-X SI DIODE
D9501 1SS355W-X SI DIODE
D9502 1SS355W-X SI DIODE
C6002 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6101 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K
C6103 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C6107 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C6109 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6111 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6112 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6113 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C6114 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6116 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C6117 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K
C6118 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C6119 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C6121 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C6122 NEHL0JM-107X E CAPACITOR 100uF 6.3V M
C6123 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6124 NEHL0JM-107X E CAPACITOR 100uF 6.3V M
C6125 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6126 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K
C6128 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K
C6130 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K
C6132 NEHL1EM-226X E CAPACITOR 22uF 25V M
C6133 NCB31CK-154X C CAPACITOR 0.15uF 16V K
C6134 NCB11AK-106X C CAPACITOR 10uF 10V K
C6135 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6139 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6217 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6218 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6221 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
C6222 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
C6236 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6237 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6238 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6239 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6241 NCB11AK-106X C CAPACITOR 10uF 10V K
C6242 NCB31AK-105X C CAPACITOR 1uF 10V K
C6243 NCB11AK-106X C CAPACITOR 10uF 10V K
C6244 NCB31AK-105X C CAPACITOR 1uF 10V K
C6245 NCB11AK-106X C CAPACITOR 10uF 10V K
C6246 NCB31AK-105X C CAPACITOR 1uF 10V K
C6247 NCB11AK-106X C CAPACITOR 10uF 10V K
C6248 NCB31AK-105X C CAPACITOR 1uF 10V K
C6249 NCB31AK-105X C CAPACITOR 1uF 10V K
C6250 NCB11AK-106X C CAPACITOR 10uF 10V K
C6251 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6252 NCB11CK-105X C CAPACITOR 1uF 16V K
C6253 NCB11CK-105X C CAPACITOR 1uF 16V K
C6254 NCB11CK-105X C CAPACITOR 1uF 16V K
C6255 NCB11CK-105X C CAPACITOR 1uF 16V K
C6260 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C6261 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C6262 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C6263 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C6268 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6270 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6271 NCB31CK-104X C CAPACITOR 0.1uF 16V K
