SW P.W. BOARD ASS'Y (SFL-7205A-H2)
LED P.W. BOARD ASS'Y (SFL-8709A-H2)
MAIN POWER P.W. BOARD ASS'Y (SFL-9049A-H2)
C6628 NEHL1EM-226X E CAPACITOR 22uF 25V M
C6629 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6630 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6631 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6632 NCB31HK-332X C CAPACITOR 3300pF 50V K
C6661 NCB11EK-105X C CAPACITOR 1uF 25V K
C6662 NCB11EK-105X C CAPACITOR 1uF 25V K
C6663 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6664 QETN1HM-226Z E CAPACITOR 22uF 50V M
C6665 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6666 QETN1HM-226Z E CAPACITOR 22uF 50V M
C6667 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6668 NCB31HK-561X C CAPACITOR 560pF 50V K
C6669 QFV21HJ-224Z MF CAPACITOR 0.22uF 50V J
C6670 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C6671 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C6672 QETN1EM-477Z E CAPACITOR 470uF 25V M
C6673 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6674 QETN1EM-477Z E CAPACITOR 470uF 25V M
C6675 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6676 NCB31HK-561X C CAPACITOR 560pF 50V K
C6677 NCB31HK-561X C CAPACITOR 560pF 50V K
C6678 QFV21HJ-224Z MF CAPACITOR 0.22uF 50V J
C6679 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C6680 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C6681 NCB31HK-561X C CAPACITOR 560pF 50V K
C6682 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6683 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6684 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6685 QETN1EM-477Z E CAPACITOR 470uF 25V M
C6686 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6687 QETN1EM-477Z E CAPACITOR 470uF 25V M
R6201 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6202 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R6203 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R6204 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R6205 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R6501 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R6502 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R6503 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6504 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R6505 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R6506 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6507 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R6601 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6602 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R6603 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6605 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6606 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R6607 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6611 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R6612 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R6613 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R6614 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6621 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R6622 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6623 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R6624 QRJ146J-102X UNF C RESISTOR 1k
Ω 1/4W J
R6625 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6626 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R6627 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6629 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6630 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R6631 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6632 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R6633 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R6634 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6661 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6662 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6663 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R6664 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R6665 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R6666 QRK126J-5R6X UNF C RESISTOR 5.6 Ω 1/2W J
R6667 QRK126J-220X UNF C RESISTOR 22
Ω 1/2W J
R6668 QRK126J-5R6X UNF C RESISTOR 5.6 Ω 1/2W J
R6669 QRK126J-220X UNF C RESISTOR 22
Ω 1/2W J
R6670 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R6671 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6673 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R6674 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R6675 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R6676 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6677 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6680 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6691 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
L6661 NQLC8CM-560X COIL 56uH M
L6662 NQLC8CM-560X COIL 56uH M
 Ref No. Part No. Part Name Description Local
K6601 NQR0499-002X FERRITE BEADS
K6602 NQR0499-002X FERRITE BEADS
K6661 NQR0499-002X FERRITE BEADS
K6662 NQR0499-002X FERRITE BEADS
K6663 NQR0499-002X FERRITE BEADS
K6664 NQR0499-002X FERRITE BEADS
TH6401 NAD0035-471X P THERMISTOR 470 Ω
 Ref No. Part No. Part Name Description Local
D7011 UDZW6.2B-X Z DIODE
C7011 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7012 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R7011 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7012 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7013 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7014 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7015 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7016 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7017 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7701 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R7702 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R7703 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R7704 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R7707 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7708 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7710 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7711 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7001 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L7002 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
J7001 QNS0097-001 3.5 JACK HEADPHONE
K7001 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
S7701 QSW1131-001Z TACT SWITCH CH-
S7702 QSW1131-001Z TACT SWITCH CH+
S7703 QSW1131-001Z TACT SWITCH MENU/OK
S7704 QSW1131-001Z TACT SWITCH TV/AV
S7705 QSW1131-001Z TACT SWITCH VOL+
S7706 QSW1131-001Z TACT SWITCH VOL-
S7707 QSW1131-001Z TACT SWITCH POWER
 Ref No. Part No. Part Name Description Local
IC8752 GP1UM261RKVF IR DETECT UNIT
Q8705 RT1P440C-X DIGI TRANSISTOR
Q8709 RT1N241C-X DIGI TRANSISTOR
Q8712 RT1N241C-X DIGI TRANSISTOR
Q8713 RT1N241C-X DIGI TRANSISTOR
D8702 SEL5E20C-T LED POWER
D8705 SELU5E20C-T LED ILLUMINATION
D8706 UDZW6.8B-X Z DIODE
D8707 UDZW6.8B-X Z DIODE
D8712 UDZW6.8B-X Z DIODE
D8713 UDZW6.8B-X Z DIODE
C8752 NEHL1CM-476X E CAPACITOR 47uF 16V M
R8714 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R8717 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8722 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R8723 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R8724 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R8755 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
 Ref No. Part No. Part Name Description Local
IC9201 MIP2C20MSSCF IC
IC9501 F9222L-F219 IC
 IC9502 FA5500AN-W IC
 IC9551 UTCTL431-T IC
 Ref No. Part No. Part Name Description Local
