JVC SP-UXJ55V User Manual

3-10
Electrical parts list
Main board
Block No. [0][1][0][0]
 Symbol No. Part No. Part Name Description Local
IC270 BA3837 IC
IC611 HA17558A IC
IC612 BU9253AS IC
IC901 LC75345M-X IC
IC931 MN101C57CEY MASK ROM
IC932 KIA7806API IC
Q2209 2SC3576-JVC-T TRANSISTOR
Q2210 2SC3576-JVC-T TRANSISTOR
Q2211 2SC2001/LK/-T TRANSISTOR
Q2219 2SC3576-JVC-T TRANSISTOR
Q2220 2SC3576-JVC-T TRANSISTOR
Q2221 KRA102M-T DIGI TRANSISTOR
Q2222 KRC104M-T TRANSISTOR
Q2780 KRC111M-T TRANSISTOR
Q2781 KRC111M-T TRANSISTOR
Q2800 KTC3199/GL/-T TRANSISTOR
Q2920 KTA1046/Y/ TRANSISTOR
Q2921 KTC3199/GL/-T TRANSISTOR
Q2922 KTC3199/GL/-T TRANSISTOR
Q2923 KRC102M-T DIGI TRANSISTOR
Q3500 KTA1267/YG/-T TRANSISTOR
Q3501 KRC104M-T TRANSISTOR
Q6001 2SC3576-JVC-T TRANSISTOR
Q6002 2SC3576-JVC-T TRANSISTOR
Q6003 KRC104M-T TRANSISTOR
Q7001 KTA1267/YG/-T TRANSISTOR
Q7002 KRC111M-T TRANSISTOR
Q7003 KTC3199/GL/-T TRANSISTOR
Q7031 KTC3199/GL/-T TRANSISTOR
Q7041 KTC3199/GL/-T TRANSISTOR
Q7061 KRC111M-T TRANSISTOR
Q7062 KRC111M-T TRANSISTOR
Q7063 KRA111M-T DIGI TRANSISTOR
Q7064 KRC111M-T TRANSISTOR
Q7080 2SA952/LK/-T TRANSISTOR
Q7081 KRC102M-T DIGI TRANSISTOR
Q7091 KRC111M-T TRANSISTOR
Q7092 KTA1267/YG/-T TRANSISTOR
D2200 1SS119-041-T2 DIODE
D2201 1SS119-041-T2 DIODE
D2204 1N4003S-T5 SI DIODE
D2205 1SS119-041-T2 DIODE
D2206 1SS119-041-T2 DIODE
D2207 1SS119-041-T2 DIODE
D2780 MTZJ5.1B-T2 Z DIODE
 D2800 MTZJ24C-T2 Z DIODE
D2804 1SS119-041-T2 DIODE
D2805 1SS119-041-T2 DIODE
D2900 MTZJ6.8C-T2 Z DIODE
D2920 1SS119-041-T2 DIODE
D2921 MTZJ5.6C-T2 Z DIODE
D2923 11EQS03LN-T2 FR DIODE
D2924 MTZJ6.8B-T2 Z DIODE
D6001 1SS119-041-T2 DIODE
D6002 1SS119-041-T2 DIODE
D6003 MTZJ5.1B-T2 Z DIODE
D7001 MTZJ5.1B-T2 Z DIODE
D7002 1SS119-041-T2 DIODE
D7003 1SS119-041-T2 DIODE
D7004 1SS119-041-T2 DIODE
D7005 1SS119-041-T2 DIODE
D7006 1SS119-041-T2 DIODE
D7007 1SS119-041-T2 DIODE
D7008 1N4003S-T5 SI DIODE
D7011 MTZJ6.2C-T2 Z DIODE
D7012 1SS119-041-T2 DIODE
D7062 1SS119-041-T2 DIODE
D7080 1SS119-041-T2 DIODE
C2000 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C2005 QETC1HM-475Z E CAPACITOR 4.7uF 50V M
C2006 QETC1HM-475Z E CAPACITOR 4.7uF 50V M
C2007 QTE1H28-106Z E CAPACITOR 10uF 50V
C2008 QETC1HM-475Z E CAPACITOR 4.7uF 50V M
C2009 QTE1H28-106Z E CAPACITOR 10uF 50V
C2010 QTE1V06-106Z E CAPACITOR 10uF 35V
C2011 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2012 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2013 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2014 QFVJ1HJ-184Z MF CAPACITOR 0.18uF 50V J
C2015 QFVJ1HJ-184Z MF CAPACITOR 0.18uF 50V J
C2016 QFVJ1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2017 QTE1H28-106Z E CAPACITOR 10uF 50V
C2018 QFVJ1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2019 QFVJ1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2026 QFLC1HJ-183Z M CAPACITOR 0.018uF 50V J
C2050 QDXB1CM-222Y C CAPACITOR 2200pF 16V M
C2100 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C2105 QETC1HM-475Z E CAPACITOR 4.7uF 50V M
C2106 QETC1HM-475Z E CAPACITOR 4.7uF 50V M
C2107 QTE1H28-106Z E CAPACITOR 10uF 50V
C2108 QETC1HM-475Z E CAPACITOR 4.7uF 50V M
C2109 QTE1H28-106Z E CAPACITOR 10uF 50V
C2110 QTE1V06-106Z E CAPACITOR 10uF 35V
C2111 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2112 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2113 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2114 QFVJ1HJ-184Z MF CAPACITOR 0.18uF 50V J
C2115 QFVJ1HJ-184Z MF CAPACITOR 0.18uF 50V J
C2116 QFVJ1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2117 QTE1H28-106Z E CAPACITOR 10uF 50V
C2118 QFVJ1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2119 QFVJ1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2126 QFLC1HJ-183Z M CAPACITOR 0.018uF 50V J
C2150 QDXB1CM-222Y C CAPACITOR 2200pF 16V M
C2200 QETM1VM-338 E CAPACITOR 3300uF 35V M
C2201 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C2207 QETN1CM-106Z E CAPACITOR 10uF 16V M
C2208 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2209 QFVJ1HJ-184Z MF CAPACITOR 0.18uF 50V J
C2210 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2211 QETN1AM-107Z E CAPACITOR 100uF 10V M
C2212 QFLM1HJ-104Z M CAPACITOR 0.1uF 50V J
C2214 QETN1AM-477Z E CAPACITOR 470uF 10V M
C2222 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2223 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2224 QETN1CM-226Z E CAPACITOR 22uF 16V M
C2228 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2250 QETC0JM-477Z E CAPACITOR 470uF 6.3V M
C2500 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2502 QDGB1HK-103Y C CAPACITOR 0.01uF 50V K
C2503 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C2504 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C2505 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C2508 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C2509 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C2510 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C2511 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C2700 QTE1H28-106Z E CAPACITOR 10uF 50V
C2721 QTE1H28-106Z E CAPACITOR 10uF 50V
C2750 QTE1H28-106Z E CAPACITOR 10uF 50V
C2751 QTE1H28-106Z E CAPACITOR 10uF 50V
C2780 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2781 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2782 QETN1CM-226Z E CAPACITOR 22uF 16V M
C2783 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2784 QDXB1CM-682Y C CAPACITOR 6800pF 16V M
C2785 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2786 QFVJ1HJ-334Z MF CAPACITOR 0.33uF 50V J
C2787 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C2820 QCBB1HK-222Y C CAPACITOR 2200pF 50V K
C2821 QCBB1HK-222Y C CAPACITOR 2200pF 50V K
C2822 QCBB1HK-473Y C CAPACITOR 0.047uF 50V K
C2823 QCBB1HK-473Y C CAPACITOR 0.047uF 50V K
 Symbol No. Part No. Part Name Description Local
