JVC SP-UXJ55V User Manual

3-13
Power board
Block No. [0][2][0][0]
 Symbol No. Part No. Part Name Description Local
IC750 GP1UM261XK IR DETECT UNIT 38kHz
 IC940 STK432-070 IC
 IC942 KIA7810API IC
Q1000 KTC3199/GL/-T TRANSISTOR
Q1001 KTC1027/OY/-T TRANSISTOR
Q1002 KTC3199/GL/-T TRANSISTOR
Q1003 2SD1266/P/ TRANSISTOR
Q4000 KTA1268/GL/-T TRANSISTOR
Q4001 KTA1268/GL/-T TRANSISTOR
Q4300 KTC3199/GL/-T TRANSISTOR
Q4301 KTA1267/YG/-T TRANSISTOR
Q4302 KTC3199/GL/-T TRANSISTOR
Q4502 2SC3576-JVC-T TRANSISTOR
Q4503 2SC3576-JVC-T TRANSISTOR
Q4504 KRA102M-T DIGI TRANSISTOR
Q7500 KRC111M-T TRANSISTOR
 D1000 1N4003S-T5 SI DIODE
 D1001 1N4003S-T5 SI DIODE
 D1002 1N4003S-T5 SI DIODE
 D1003 1N4003S-T5 SI DIODE
 D1004 1N5401-TM SI DIODE
 D1005 1N5401-TM SI DIODE
 D1006 1N5401-TM SI DIODE
 D1007 1N5401-TM SI DIODE
D1008 1SS119-041-T2 DIODE
D1009 1N4003S-T5 SI DIODE
D1011 MTZJ6.2C-T2 Z DIODE
D1012 1SS119-041-T2 DIODE
D1013 MTZJ5.1B-T2 Z DIODE
D1014 MTZJ11C-T2 Z DIODE
D4000 1SS119-041-T2 DIODE
D4001 1SS119-041-T2 DIODE
 D4002 MTZJ9.1B-T2 Z DIODE
 D4003 MTZJ9.1B-T2 Z DIODE
 D4200 MTZJ11B-T2 Z DIODE
D4202 1SS119-041-T2 DIODE
D4300 1SS119-041-T2 DIODE
D7303 SELU1E54CM-S LED
D7304 SELU1E54CM-S LED
D7305 SELU1E54CM-S LED
D7501 1SS119-041-T2 DIODE
D7502 SPR-39MVWF LED RED-GREEN
D7503 1SS119-041-T2 DIODE
D7600 SELU1E54CM-S LED
D7602 SELU1E54CM-S LED
D7604 SELU1E54CM-S LED
C1000 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1001 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1002 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1003 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1004 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C1005 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C1006 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C1007 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
 C1008 QCZ9105-472 C CAPACITOR 4700pF 250V M
C1009 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C1010 EETC0JM-477ZJC C CAPACITOR
C1011 QETM1JM-477 E CAPACITOR 470uF 63V M
C1012 EETC1HM-106ZJC E CAPACITOR
C1014 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C4000 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C4001 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C4002 QTE1V06-106Z E CAPACITOR 10uF 35V
C4003 QTE1V06-106Z E CAPACITOR 10uF 35V
C4006 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C4007 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C4008 QETC1HM-476Z E CAPACITOR 47uF 50V M
C4009 QETC1HM-476Z E CAPACITOR 47uF 50V M
C4010 QCSB1HJ-100Y C CAPACITOR 10pF 50V J
C4011 QCSB1HJ-100Y C CAPACITOR 10pF 50V J
C4012 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4013 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4014 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4015 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4016 FQCF31HZ-223Z D.CAPACITOR
C4017 FQCF31HZ-223Z D.CAPACITOR
C4030 QETN1HM-476Z E CAPACITOR 47uF 50V M
C4031 QETC1HM-106Z E CAPACITOR 10uF 50V M
C4032 QETC1HM-106Z E CAPACITOR 10uF 50V M
C4033 QETN1HM-476Z E CAPACITOR 47uF 50V M
C4035 FQCF31HZ-223Z D.CAPACITOR
C4036 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C4037 QETM1HM-228 E CAPACITOR 2200uF 50V M
C4038 QETM1HM-228 E CAPACITOR 2200uF 50V M
C4200 QETN1HM-106Z E CAPACITOR 10uF 50V M
C4201 QETN1CM-106Z E CAPACITOR 10uF 16V M
C4301 QETC1EM-226Z E CAPACITOR 22uF 25V M
C4302 QETC1CM-476Z E CAPACITOR 47uF 16V M
C4303 QETC1HM-226Z E CAPACITOR 22uF 50V M
C4500 QETC1EM-106Z E CAPACITOR 10uF 25V M
C5010 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C5011 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7501 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C7502 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7503 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C7504 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7507 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7510 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7511 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7520 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7600 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
R1001 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1002 QRE141J-821Y C RESISTOR 820 Ω 1/4W J
R1003 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R1004 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R1005 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
 R1010 QRZ9042-2R2X F RESISTOR 2.2 Ω
R1011 QRE141J-822Y C RESISTOR 8.2k Ω 1/4W J
R1012 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R4000 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R4001 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R4002 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R4003 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R4004 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
R4005 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
R4006 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
R4007 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
 R4008 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R4009 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R4010 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R4011 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R4012 FQRJ143J-821X UNF C RESISTOR
R4013 FQRJ143J-821X UNF C RESISTOR
R4014 FQRJ143J-100X UNF C RESISTOR
R4015 FQRJ143J-100X UNF C RESISTOR
R4016 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R4017 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R4018 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R4019 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R4020 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R4021 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R4022 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R4023 QRE141J-392Y C RESISTOR 3.9k
Ω 1/4W J
R4030 QRE141J-333Y C RESISTOR 33k
Ω 1/4W J
R4031 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
R4032 QRJ146J-101X UNF C RESISTOR 100
Ω 1/4W J
R4033 QRJ146J-100X UNF C RESISTOR 10
Ω 1/4W J
 R4036 QRZ9006-4R7X FUSI RESISTOR 4.7 Ω 1/4W J
R4201 QRT01DJ-R33X MF RESISTOR 0.33
Ω 1W J
R4202 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R4203 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R4204 QRT01DJ-R33X MF RESISTOR 0.33
Ω 1W J
R4300 QRE141J-823Y C RESISTOR 82k Ω 1/4W J
R4301 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R4302 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R4303 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R4304 QRE141J-124Y C RESISTOR 120k
Ω 1/4W J
R4305 QRE141J-122Y C RESISTOR 1.2k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
