JVC SP-UXJ55V User Manual

(No.MB057)1-7
SECTION 3
DISASSEMBLY
3.1 Main body
3.1.1 Removing the metal cover
(See Fig.1~3)
(1) Pull out the MIC volume knob on top of the body.
(2) Remove the six screws A on the back of the main body.
(3) Remove the two screws B on each side and remove the
metal cover in the direction of the arrow.
Fig.1
Fig.2
Fig.3
Metal cover
Volume knob
A
A
A
B
B
