3-15
Tuner board
Block No. [0][4][0][0]
C832 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C833 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C851 NCS31HJ-330X C CAPACITOR 33pF 50V J
C852 NCS31HJ-330X C CAPACITOR 33pF 50V J
C853 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C854 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C855 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
R601 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R602 NRSA63J-274X MG RESISTOR 270k Ω 1/16W J
R603 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R604 NRSA63J-274X MG RESISTOR 270k Ω 1/16W J
R605 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R606 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R607 NRSA63J-623X MG RESISTOR 62k Ω 1/16W J
R610 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R611 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R612 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R613 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R615 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R616 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R617 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R631 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R632 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R634 NRSA63J-120X MG RESISTOR 12 Ω 1/16W J
R635 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R636 NRSA63J-910X MG RESISTOR 91 Ω 1/16W J
R641 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R642 NRSA63J-564X MG RESISTOR 560k Ω 1/16W J
R643 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R647 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R651 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R652 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R653 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R655 NRSA63J-510X MG RESISTOR 51 Ω 1/16W J
R656 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R657 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R658 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R659 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R661 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R662 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R663 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R664 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R665 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R666 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R667 NRSA63J-4R7X MG RESISTOR 4.7 Ω 1/16W J
R670 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R681 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R682 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R683 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R684 NRSA63J-155X MG RESISTOR 1.5M Ω 1/16W J
R801 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R802 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R803 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R804 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R805 NRSA63J-912X MG RESISTOR 9.1k
Ω 1/16W J
R806 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R807 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R808 NRSA63J-433X MG RESISTOR 43k Ω 1/16W J
R809 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R819 QRE141J-2R2Y C RESISTOR 2.2
Ω 1/4W J
R820 QRE141J-2R2Y C RESISTOR 2.2 Ω 1/4W J
R822 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R831 QRE141J-100Y C RESISTOR 10
Ω 1/4W J
R851 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R852 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R853 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R854 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R855 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R856 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R858 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R859 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R860 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R861 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R862 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R863 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R864 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R865 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R866 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R867 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R868 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R869 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R870 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R871 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R872 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R873 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R874 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R875 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R876 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R881 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R882 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R883 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R884 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R885 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
L831 QQL244K-100Z COIL 10uH K
CN601 QGF1016F3-16 CONNECTOR FFC/FPC (1-16)
CN606 QGF1205F1-05 CONNECTOR FFC/FPC (1-5)
CN651 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN652 QGF1036F1-19 CONNECTOR FFC/FPC (1-19)
CN801 QGA2001C1-06 CONNECTOR W-B (1-6)
SP602 VYSA1R4-100 SPACER
X651 QAX0413-001Z CRYSTAL 16.9344MHz
X851 QAX0283-001Z C RESONATOR 8.000MHz
 Symbol No. Part No. Part Name Description Local
IC1 LA1838 IC
IC2 LC72136N IC
Q1 2SC2814/4-5/-X TRANSISTOR
Q5 KRA107S-X DIGI TRANSISTOR
D1 1SS133-T2 DIODE
D2 1SS133-T2 DIODE
D3 1SS133-T2 DIODE
D4 1SS133-T2 DIODE
D11 1SS133-T2 DIODE
C1 NCB21HK-223X C CAPACITOR 0.022uF 50V K
C2 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C3 EETC1CM-106ZJC E CAPACITOR
C4 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C6 NCB21HK-102X C CAPACITOR 1000pF 50V K
C7 NCB21HK-102X C CAPACITOR 1000pF 50V K
C8 NCB21HK-102X C CAPACITOR 1000pF 50V K
C10 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
C11 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C12 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C13 NCS21HJ-100X C CAPACITOR 10pF 50V J
C14 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C15 NCS21HJ-120X C CAPACITOR 12pF 50V J
C16 NCS21HJ-120X C CAPACITOR 12pF 50V J
C17 NCB21HK-392X C CAPACITOR 3900pF 50V K
C18 QEQ61HM-474Z E CAPACITOR 0.47uF 50V M
C19 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C20 NCB21HK-102X C CAPACITOR 1000pF 50V K
C21 NCB21HK-223X C CAPACITOR 0.022uF 50V K
C22 NCS21HJ-151X C CAPACITOR 150pF 50V J
C23 NCS21HJ-151X C CAPACITOR 150pF 50V J
C24 NCS21HJ-151X C CAPACITOR 150pF 50V J
C25 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C26 NCB21HK-102X C CAPACITOR 1000pF 50V K
C27 NCB21HK-102X C CAPACITOR 1000pF 50V K
C30 EEKC1CM-107ZJC E CAPACITOR
C31 EEKC1CM-226ZJC E CAPACITOR
C32 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C33 NCB21HK-473X C CAPACITOR 0.047uF 50V K
 Symbol No. Part No. Part Name Description Local
