JVC TH-P5 User Manual

39
References
7 Center unit (XV-THP5/XV-THP3)
Audio section
Front/Surround: 40 W per channel, RMS at 3 Ω at
1 kHz, with 10 % total harmonic
distortion.
Center: 100
W, R M S a t 4 Ω at 1 kHz, with
10 % total harmonic distortion.
Subwoofer: 100
W, R M S a t 4 Ω at 30 Hz, with
10 % total harmonic distortion.
Video section
Video System: PAL
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 64 dB
(Composite signal when “RGB” is selected)
Video output level
Composite: 1.0 V(p-p)/75 Ω
Y: 1.0 V(p-p)/75 Ω
C: 0.3 V(p-p)/75 Ω
RGB: 0.7 V(p-p)/75 Ω
Only for XV-THP5:
Component-Y: 1.0 V(p-p)/75 Ω
Component-P
B/PR: 0.7 V(p-p)/75 Ω
USB storage
USB specification: Compatible with the USB 2.0 Full-
Speed
Compatible device: Mass Storage Class
Compatible file system: FAT16, FAT32
Bus power supply: Max. 500 mA
Tuner section
Tuning Range
FM: 87.50 MHz to 108.00 MHz
AM (MW): 522 kHz to 1 629 kHz
General
Power Requirements: AC 230 V , 50 Hz
Power Consumption: 60 W (at operation)
1.4 W (in standby mode)
Dimensions (W M H M D):
435 mm M 70 mm M 308 mm
Mass: 3.0 kg
7 Subwoofer (SP-WP5)
Type: Bass-Reflex Type
Speaker: 16 cm cone M 1
Power Handling Capacity: 100 W
Impedance: 4 Ω
Frequency Range: 35 Hz to 200 Hz
Sound Pressure Level: 75 dB/W·m
Dimensions (W M H M D):
129 mm M 284 mm M 337 mm
Mass: 3.1 kg
7 Satellite speakers (For TH-P5)
Front speakers (SP-THP5F)
Type: 3-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker: 11.5 cm cone M 1
4 cm cone M 1
1.5 cm cone M 1
Power Handling Capacity: 40 W
Impedance: 3 Ω
Frequency Range: 60 Hz to 20 000 Hz
Sound Pressure Level: 82 dB/W·m
Dimensions (W M H M D):
146 mm M 246.5 mm M 208 mm
Mass: 2.2 kg each
Center speaker (SP-THP5C)
Type: 1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker: 6.5 cm cone M 2
Power Handling Capacity: 100 W
Impedance: 4 Ω
Frequency Range: 90 Hz to 20 000 Hz
Sound Pressure Level: 79 dB/W·m
Dimensions (W M H M D):
250 mm M 85 mm M 91 mm
Mass: 0.82 kg
Surround speakers (SP-THP5S)
Type: 1-Way Bass-Reflex Type
Speaker: 6.5 cm cone M 1
Power Handling Capacity: 40 W
Impedance: 3 Ω
Frequency Range: 90 Hz to 20 000 Hz
Sound Pressure Level: 72 dB/W·m
Dimensions (W M H M D):
79.5 mm M 147 mm M 88 mm
Mass: 0.51 kg each
Specifications
THP5-P3[B]-f.book Page 39 Tuesday, December 27, 2005 3:39 PM

JVC TH-P5 Specifications

General

Audio decoders	Dolby Digital, Dolby Pro Logic II, DTS
RMS rated power	360 W
Audio output channels	5.1 channels
Audio formats supported	MP3, WMA
Total Harmonic Distortion (THD)	10 %
Satellite speakers RMS power	40 W
Satellite speaker frequency range	90 - 20000 Hz
I/O ports	SCART (met RGB) \\t Component video uit \\t USB Host SCART (RGB) \\t SCART (composiet) \\t SCART (S-Video-Y) \\t SCART (S-Video-C) \\t Component (Y) \\t Component (Pb/Pr)
Power requirements	230 V AC /50 Hz
Surround speaker weight	510 g
Surround speaker dimensions (WxHxD)	79.5 x 88 x 147 mm
Disc types supported	DVD-R, DVD-RW
Optical disc player type	DVD recorder
Power consumption (standby)	1.4 W
Power consumption (typical)	60 W

Weight and Dimensions

Subwoofer weight	3100 g
Center speaker weight	820 g
Subwoofer dimensions (WxDxH)	129 x 337 x 284 mm
Center speaker dimensions (WxDxH)	250 x 85 x 91 mm
