Model 2400 Service Manual 6-4
Replaceable Parts
Table 6-1
Analog board parts list
Circuit designation Description
Keithley
part no.
C200-203,205-210,225, 226,231,232,237,238,
242,243,248-255,258-261,269-272,
273-282,284-291,297-300,524,525,
530,531,542,548,549,554,605-607,613,
614,617-625,650-652,659-662
CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C204,404,550-553,608,609 CAP, .01UF, 10%, 50V, CERAMIC C-491-.01
C211-214 CAP, 1000PF, 10%, 50V, MONO CERAMIC C-452-1000P
C215-222,611 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C223,224,227-230,233-236,239-240 CAP, 33PF, 5%, 100V, CERAMIC C-465-33P
C241 CAP, 1000PF, 1%, 50V, CERAMIC C-347-1000P
C244,245 CAP, .022UF, 10%, 50V, CERAMIC C-491-.022
C246,513 CAP, 560PF, 2.5%, 630V, POLYPROPYLENE C-405-560P
C247,267,268 CAP, 1000P, 10%, 100V CERAMIC C-451-1000P
C256,257 CAP, 22PF, 10%, 100V, CERAMIC C-451-22P
C283 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C301,302 CAP, 1000PF, 10%, 50V, MONO CERAMIC C-452-1000P
C311 CAP, 100UF, 20%, 10V, ALUM ELEC C-483-100
C312-319,329 CAP, 10PF, 5%, 100V, CERAMIC C-372-10P
C320,323-326,603,604,615 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C330 CAP, 100PF, 2.5%, 630V, POLYPROPYLENE C-405-100P
C331-334 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C296,400,408 CAP, 270PF, 2.5%, 630V, POLYPROPYLENE C-405-270P
C401,402 CAP, 10PF, .5%, 500V, POLYSTYRENE C-405-10P
C405,406 CAP, .15UF, 20%, 50V, CERAMIC C-418-.15
C407 CAP, 1UF, 20%, 35V, TANTALUM C-494-1
C500-503 CAP, 4.7UF, 20%, 350V, ALUM ELEC C-393-4.7
C504,505,534,535 CAP, 47UF, 20%, 100V, ALUM ELEC C-521-47
C512,514 CAP, 22PF, 10%, 100V, CERAMIC C-451-22P
C515,541 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C522,523,526-529,532,533 CAP, 1000P, ±10%, 500V, CERAMIC C-497-1000P
C537,538 CAP, .1UF, 10%, 500V, X7R C-525-.1
C539,540 CAP, 1UF, 20%, 50V, CERAMIC C-519-1
C543 CAP, 10PF, 10%, 1000V, CERAMIC C-64-10P
C544-547 CAP, 2200P, ±10%, 500V, CERAMIC C-497-2200P
C610,612 CAP, 2200P, 10%, 100V, CERAMIC C-430-2200P
C616 CAP, 22UF, 20%, 25V, TANTALUM C-440-22
CR200-203,205,207,208,210,212,213,216,
221,235,236,602
DIODE, SWITCHING, MMBD914 RF-83
CR204,206,209,211,222-225,230-233,400,
401,502-504
DIODE, IN3595 RF-43
CR236,602,212,213 ULTRAFAST POWER RECTIFIER RF-105
CR237 DIODE, DUAL SWITCHING, BAV99L RF-82
