SPECIFICATIONS
SPEC-2400
A 18217 Released SZ 1/11/96
B 18249 Revised SZ 3/6/96
C 18608 Revised SZ 4/22/96
D 18863 Revised SZ 7/29/96
E 19739 Revised SZ 10/4/98
F 27103 Revised SZ 5/10/02
G 27953 Revised SZ 3/04/03
H 29424 Revised SZ 2/25/04
HW 2/25/04
Rev. H
Page 1 of 3
2400, 2400-LV and 2400-C SourceMeter
®
Specifications
SOURCE SPECIFICATIONS
1
VOLTAGE PROGRAMMING ACCURACY (LOCAL OR REMOTE SENSE)
MODEL RANGE
PROGRAMMING
RESOLUTION
ACCURACY (1 Year)
23°C ±5°C
±(% rdg. + volts)
NOISE
(peak-peak)
0.1Hz – 10Hz
200.00 mV 5 µV 0.02% + 600 µV 5 µV
2.00000 V 50 µV 0.02% + 600 µV 50 µV
20.0000 V 500 µV 0.02% + 2.4 mV 500 µV
2400-C and
2400 Only:
200.00 V 5 mV 0.02% + 24 mV 5 mV
TEMPERATURE COEFFICIENT (0°-18°C & 28°-50°C): ±(0.15 × accuracy
specification)/ °C.
MAX. OUTPUT POWER: 22W, four quadrant source or sink operation.
SOURCE/SINK LIMITS:
MODEL 2400, 2400-C:
±21V @ ±1.05A, ±210V @ ±105 mA.
MODEL 2400-LV: ±21V @ ±1.05A.
VOLTAGE REGULATION: Line: 0.01% of range. Load: 0.01% of range + 100
µV.
NOISE 10Hz – 1MHz (p-p): 10mV typical into a resistive load.
OVERVOLTAGE PROTECTION: User selectable values, 5% tolerance. Factory
default = none.
CURRENT LIMIT: Bipolar current limit (compliance) set with single value. Min.
0.1% of range.
OVERSHOOT: <0.1% typical (full scale step, resistive load, 10mA range).
CURRENT PROGRAMMING ACCURACY (LOCAL OR REMOTE SENSE)
RANGE
PROGRAMMING
RESOLUTION
ACCURACY (1 Year)
3
23°C ±5°C
±(% rdg. + amps)
NOISE
(peak-peak)
0.1Hz – 10Hz
1.00000 µA 50 pA 0.035% + 600 pA 5 pA
10.0000 µA 500 pA 0.033% + 2 nA 50 pA
100.000 µA 5 nA 0.031% + 20 nA 500 pA
1.00000 mA 50 nA 0.034% + 200 nA 5 nA
10.0000 mA 500 nA 0.045% + 2 µA 50 nA
100.000 mA 5 µA 0.066% + 20 µA 500 nA
1.00000 A
2
50 µA 0.27% + 900 µA 5 µA
TEMPERATURE COEFFICIENT (0°-18°C & 28°-50°C): ±(0.15 × accuracy
specification)/ °C.
MAX. OUTPUT POWER: 22W, four quadrant source or sink operation.
SOURCE/SINK LIMITS: 2400, 2400-C:
±1.05A @ ±21V, ±105 mA @ ±210V.
2400-LV: ±1.05A @ ±21V.
CURRENT REGULATION: Line: 0.01% of range. Load: 0.01% of range + 100
pA.
VOLTAGE LIMIT: Bipolar voltage limit (compliance) set with single value. Min.
0.1% of range.
OVERSHOOT: <0.1% typical (1mA step, RL = 10kΩ, 20V range).
ADDITIONAL SOURCE SPECIFICATIONS
TRANSIENT RESPONSE TIME: 30µs minimum for the output to
recover to its spec. following a step change in load
.
COMMAND PROCESSING TIME: Maximum time required for the
output to begin to change following the receipt of
:SOURce:VOLTage|CURRent <nrf> command. Autorange On:
10ms. Autorange Off: 7ms.
OUTPUT SETTLING TIME: Time required to reach 0.1% of final
value after command is processed. 100µs typical. Resistive load.
10µA to 100mA range.
OUTPUT SLEW RATE (±30%): 0.5V/µs, 200V range, 100mA
compliance. (2400 and 2400-C
only)
0.08V/µs, 20V range, 100mA
compliance.
DC FLOATING VOLTAGE: Output can be floated up to ±250VDC
from chassis ground.
REMOTE SENSE: Up to 1V drop per load lead.
COMPLIANCE ACCURACY: Add 0.3% of range and ±0.02% of
reading to base specification.
OVER TEMPERATURE PROTECTION: Internally sensed
temperature overload puts unit in standby mode.
RANGE CHANGE OVERSHOOT: Overshoot into a fully resistive
100kΩ load, 10Hz to 1MHz BW, adjacent range changes between
200mV, 2V and 20V ranges, 100mV typical.
MINIMUM COMPLIANCE VALUE: 0.1% of range.
1. Specifications valid for continuous output currents below 105mA. For operation
above 105mA continuous for > 1 minute, derate accuracy 10%/35mA above
105mA.
2. Full operation (1A) regardless of load to 30°C. Above 30°C ambient, derate
35mA/°C and prorate 35mA/Ω load. 4-wire mode. For current sink operation on
1A range, maximum continuous power is limited to approximately 1/2 rated
power or less, depending on current, up to 30°C ambient. See power equations in
the User’s Manual to calculate allowable duty cycle for specific conditions.
3. For sink mode, 1µA to 100mA range, accuracy is:
±(0.15% + offset*4)
For 1A range, accuracy is:
±(1.5% + offset*8)
