Keithley 2635 User Manual

1-10 Return to Section Topics 2600S-900-01 Rev. C / January 2008
Section 1: Front and Rear Panel Operation Series 2600 System SourceMeter
®
Instruments User’s Manual
What are the source-measure capabilities?
Reference See the specifications in Appendix A of this manual as well as Sections 4 and 8 of
the Series 2600 Reference Manual for more detailed information.
Model 2601 and Model 2602
Basic DC source-measure capabilities for the Models 2601 and 2602 are listed in Table 1-3.
Table 1-3
Model 2601 and 2602 source-measure capabilities
Function Capabilities
Source ±DC voltage
Source ±DC current
1μV to 40.4V
1pA to 3.03A
1
Measure ±DC voltage
Measure ±DC current
1μV to 40.8V
1pA to 3.06A
1
1. 10A maximum available in pulse mode only.
Model 2611 and Model 2612
Basic DC source-measure capabilities for the Models 2611 and 2612 are listed in Table 1-4.
Table 1-4
Model 2611 and 2612 source-measure capabilities
Function Capabilities
Source ±DC voltage
Source ±DC current
1μV to 202V
1pA to 1.515A
1
Measure ±DC voltage
Measure ±DC current
1μV to 204V
1pA to 1.53A
1
1. 10A maximum available in pulse mode only.
Model 2635 and Model 2636
Basic DC source-measure capabilities for the Models 2635 and 2636 are listed in Table 1-5.
Table 1-5
Model 2635 and 2636 source-measure capabilities
Function Capabilities
Source ±DC voltage
Source ±DC current
1μV to 202V
20fA to 1.515A
Measure ±DC voltage
Measure ±DC current
1μV to 204V
1fA to 1.53A
